MLC500 Auto Ranging LC Meter Tester+MESR100 in Circuit ESR Capacitor Meter Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge MLC500 Auto Ranging LC Meter, 500 KHz test+MESR-100 Auto Ranging Please Note: a) Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer’s responsibility. b) Please check with your country’s customs office to determine what these additional costs will be prior to bidding/buying. MLC500 LC meter is auto-ranging component tester, can drive up to 500 KHz, suitable for small value capacitor and inductor measurement. It provides very stable and high resolution measurement up to 5 digits. Meter can measure 0.00pF to 100.00mF capacitance and 0.000uH to 100.00H This meter is using two technique measurement, LC oscillation and RC oscillation. LC is much suitable for small value measurement and RC for high value capacitance. *Discharge Capacitor before Testing!! * Please don’t connect under testing device during power on, it will affect the initialization. Features: - Fully auto-ranging designed - High resolution, up to 5 digit display, finest resolution: 0.01pF, 0.001uH - High stability and measurement range for L/ C - 128X64 Large LCD display with backlight - USB PC program, can take record and pass and fail component sorting function. - Capacitor discharge terminal and capacitor storage voltage display. Specification: Model: MLC500 LC Meter Series LCR Testing Parameter Main Parameter: L / C Testing frequency C: 10 to 500Khz L: 10 to 360Khz Testing Method Auto select LC and RC Oscillation Calibration Power on auto calibrate with internal reference capacitor Testing voltage ~1.5Vrms Best Tolerance L: 1% +1 Digit C: 1% +1 Digit LCD update or Testing time (* vary on component value) <3/s, (e.g. 100mF Capacitor <30s) Range Selection Automatically Zeroing Open / short circuit Terminal Mini-USB(Virtual Com Port) Display Range C 0.00pF ~100.000mF (pF/nF/uF/mF) L 0.000uH ~100.000H (uH/mH/H) Hz (LC Oscillation Frequency) 0 to 900000Hz (s) (RC Constant Time) 0.000 to 99.999 LCD Display 128X64 Dot Matrix, with backlight Fuse Protection No Battery 2XAA 1.5V battery Number of Testing Terminal Main 3, Secondary 2 Reading Display Max. 99999 Package: 1) 1 pcs MLC500 2) 1 set Manual 3) Test clip Get MESR-100 for Four Reasons: 1. JINGYAN MESR-100 V2 Auto-ranging capacitor ESR and Low Ohm Meter 2. Measuring range from 0.001 to 100.0R, support IN CIRCUIT Testing. 3. Using true 100 KHz sine wave to measure the ESR value, which is equal to the testing method of capacitor manufacturer. 4. In the market, there is some technique using short pulse method to testing, but the value will be varying vs the capacitance and sometimes reading is different from the manufacturer's value. What is ESR of capacitor? 1)There is a series resistor inside capacitor, using 100kHz to remove the impedance 1/(2*pi*F*C), the impedance become small, and we can then measure the true series resistor value. 2)A bad E-capacitor will have larger ESR and create large ripple rather than filtering noise. Normally, a big capacitor is larger than 3 ohm. 3)Using this theory, we can measure the capacitor is bad/ damaged or good in condition. 4)Because our ESR meter only applies less than 15mV DC or peak to peak on a good capacitor, as a result we can use it as in circuit test. Because this low testing voltage, it cannot turn on the semiconductor inside a circuit under testing. 5)During repairing TV, LCD, Audio board, etc. we can in circuit testing the capacitor is good or not. 6)Dual terminal, for fast and easy inspect general capacitor or resistor, a printed ESR table for fast check Compare MESR100 old V1 and new V2 Improvement: 1. Change square wave to sine wave 100 KHz, reduce square wave’s high frequency component, and affect the reading passing the test leads and capacitor. 2. Higher Resolution up to 0.001 ohm. 3. Support external USB power, using standard micro-USB port. 4. 128X64 dot matrix LCD, with more larger value display and information 5. New plastic case, curve design for hand carrying. New stand for 60 degree stand on desk. 6. Use 2X AA battery, more convenience and longer battery life than 9V battery. 7. Embedded 25V capacitor table at LCD, auto display the capacitor is good or bad reference to common 25V electrolytic capacitor. Specification: Range Accuracy (After Zero, tested with 1,10,100R resistor) Refresh Time (Manual Mode) *Auto mode take 0 to 2s more time depend on value 0.000 to 1.000R 1%+2Digit ~0.4s 1.000 to 10.00R 1%+1Digit ~0.4s 10.00 to 100.0R 2%+1Digit ~0.4s Accuracy maybe affected by the test lead’s length and contact point resistance. Standard test leads is 15cm, for longer test leads need special shielding to affect the EMI inference (Can contact sales’ person for more detail) 1) Accuracy: Up to 1% (detail on above table) Wide Measurement Range: >1uF (for 0.1uF the error will be larger on equation 1/(2*pi*F*C) @ 100Khz ) 2) High Resolution: 4 digit, or 0.001Ohm @ 1 Ohm range 3) Measuring voltage: <~40mV RMS (TESTING VOLTAGE) 4) Clamping voltage: ~0.15V (open voltage) 5) Battery 2X AA 1.5V battery 6) External Power: 5V micro USB 7) Operating current 0.02A 8) Battery Life time: >80 Hours Operating Introduction: 1) POWER ON Press and hold the ON/ OFF circle orange button for 2 to 3 second to power on. Press and release the ON/ OFF button to shut down meter. 2) AUTO/ MANUAL mode: i) Auto Range: Press and release the RANGE button and at the first line of LCD will show “AUTO:" At auto mode meter will automatically select the best range to detect. ii) Manual Range: Scroll the manual range from 1R, 10R and 100R range by press and release the RANGE button In LCD will show MANUAL at first LCD line and show at second line: 0-1R, 1-10R and 10-100R. 3) 1 Key Zero: Short circuit the test leads’ terminal, cancelling the wire resistance. Press and release the “ZERO" button, LCD shows “ZERO" and wait the zero disappear. If you are using the meter array socket, you need to use a short pin to short circuit to set zero. 4) Backlight: LCD backlight will on during power on 5) Auto Sleep: Around 10 hours for not testing, it will shut down automatically to save power. 6) OVERFLOW or OL: Display overflow when the value is out of range, you can check that you are zero correctly. 7) ESR TABLE: It is for reference only, different manufacturer of capacitor has different ESR, better to test a good cap ESR and compare with what you are testing, usually bad cap with higher ESR few times larger than good one. 8) SOFTWARE ESR: Put the 25V Electrolytic capacitor value to LCD, and compare, GOOD if C < XXuF, means the capacitor maybe good condition if it is less than XXuF 9) PLASTIC STAND: If you don’t use the stand, press and push the lock position: Package including: 1unit x MESR-100 V2 1pair x 15cm test clips (as photo) Warranty 1. One-year guarantee for most items. 2. Each item will be checked and tested carefully by our QC before sent out. 3. Unlimited Technical Service is offered through e-mails, on-line chatting, remote-control service by engineers. 4. 14-day Money back & Exchange Service is provided after you received the item. 5. Please make sure it is the item you want before order it,if you made a mistake and order a wrong item, we accept 14-day Money back & Exchange. But Buyers should cover shipping cost both ways. Customer Service Dear friend,Welcome to contact us. Customer Service Available: Customer Service is not available on Saturday afternoon & Sunday. 1. If any problem, pls feel free to contact us through "My message'' or "ask seller question". 2. We are in different time zones, during the working time, we will reply your email within 24 hours. 3.If we can not reply to you, maybe we are not in office or we don't receive your letter,so pls send it again! Your satisfactory is our top concern. We sincerely apologize for the inconvenience caused by time difference. Feedback We maintain high standards of excellence and strive for 100% customer satisfaction! Feedback is very important to us.We request that you contact us Immediately BEFORE you give us a neutralor negative feedback so that we can satisfactorily address your concerns. Step1: Leave the Posivive rating Step2: Leave your comments about this deal Step3: Choose the five star rating for every detailed, it's very important for us. Item as described Communication Shipping time Shipping and handling charges Payment We only accept paypal E-Check will be held until cleared. 1. We prefer to accept paypal as our payment method. It is quick and safe. 2. Please make payment within 4 days after biding, or all non-pay bidders will result in a non-paymemt buyer alert from Ebay and unpaid transaction would be closed. Notice: Pls leave your specific shipping address and your phone number. Shipping 1. We ship to WORLDWIDE excluding Brazil,France, Italy etc. 2. Item will be shipped out within 1 working days (except weekends and holidays) after the payment is cleared or received. We will send item to your Confirmed Shipping Address in Paypal. 3. If you would like to post to other address , please timely leave us a note when making payment through Paypal. We will NOT be responsible for any delivery failure due to unclear,unconfirmed or incomplete addresses given. 4. We ship by Singapore Post, HongKong Post, E-Packet, DHL/EMS, exact delivery time varies by shipping methods and your location. Usually the standard service delivery takes 15-20 working days (except weekends and holidays), If you don't receive the item after the 30 days, please contact us freely, we'll try our best to solve the delivery problem. About Us Welcome to our eBay store:supershop2050! We sell OBD2 Auto diagnostic tool and professional automotive mechanics with Top Quality,Good Service,Competitive Price,such as super vag k+can,MVCI,Mini Vci,Ak90 etc. High product quality, reasonable prices, excellent customer service and a reliable credit standing is our tenet. Please sign up by adding our eBay shop to your "My Favorite Sellers and stores" list. Please come back soon and visit us again! Wish You a Happy Online Shopping! We would ship out the item within 1 business days after the payment is received.Our QC will test goods carefully before sent out. The package will be sent by AirMail. Normally delivery days is within 15-20 working days We will send item to your Confirmed Shipping Address in PayPal. If you would like to post to other address , please timely leave us a note when making payment through PayPal. We hope it arrive on time but since this is an international delivery, shipping time will be highly depended on the courier company and local customs/duties. If you don't receive the item after the 25 days, please contact us freely, we'll try our best to solve the delivery problem. We only accept paypal , E-Check will be held until cleared. Please make payment within 3 days after bidding, or all non-pay bidders will result in a non-paymemt buyer alert from Ebay and unpaid transcation would be closed.Please do not bid if you are not going to pay for the auctions, please be a serious bidder. DO NOT DUPLICATE OR COPY! Template Made By: © InkFrog.com Auction Templates, Logos, Store fronts and more! inkfrog terapeak i000000 inkFrog Analytics
