model Associated "Hired Man" hit & miss engine castings & drawings AIR COOLED, US $155.00 – Picture 0
model Associated "Hired Man" hit & miss engine castings & drawings AIR COOLED, US $155.00 – Picture 0

Model Associated "hired Man" Hit & Miss Engine Castings & Drawings Air Cooled

US $155.00

  • Lancaster, Pennsylvania, United States
  • Mar 4th
Open on mobile:
QR code
Rough castings and drawings to make a 1/3 scale model Spark Plug Ignition, Air Cooled model of a Associated "Hired Man" hit & miss engine. Only items shown in the photo are included. Iron castings include the Base, Bearing caps, Cylinder, Cylinder head, and 2 Flywheels. 1 Bronze Connecting Rod. Full set of drawings showing all details including how to machine crankshaft, make a spark plug, and a gas tank. Current drawings show ignition points that may be hard to obtain and will have to substitute or use Hall effect sensor. Gears are NOT supplied. You can obtain them from Boston Gear numbers G181 & G173 or Amazon.com. You supply all other materials and machine on your lathe and milling machine and fabricate the necessary parts to assemble a engine that actually runs. Flywheel rough OD 6.25in / Cylinder Bore 1.25in. Ships in a medium Flat Rate box. Checkout will determine correct postage. Will ship worldwide.
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Country/Region of Manufacture United States
