Moore No 3 Jig Grinder 4 High Speed Spindle Heads 175,000 Rpm Spindle 4 Heads

US $14,500.00

Hopkins, Minnesota, United States
Jan 30th

Open on mobile:
QR code

HERE IS A NICE WORKING MOORE NO 3 JIG GRINDER WITH 4 HIGH SPEED SPINDLES AND TOOLING. THIS GRINDER CAN BE INSPECTED UNDER POWER IN MPLS MN. TO SET UP AN INSPECTION PLEASE CALL JIM @ 952-931-7974. THANK YOU. NOTE: THIS MACHINE HAS THE DIGITAL SCALES AND READ OUT PLUGS CONNECTED TO THE MACHINE. THE SONY MAGNA SCALE LU 10 DIGITAL READ OUT BOX WAS LOST IN SHIPMENT. GENERAL SPECIFICATIONS: MAKE: MOORE MODEL: NO 3 JIG GRINDER SN: G-874 TABLE SIZE .................................... 11" X 24" RANGE: TABLE MOVEMENT ................................ 11" X 18" TABLE TOP TO WHEEL COLLET ...................... 2" X 18" SPINDLE TO COLUMN WAYS .............................. 10" SPINDLE TO COLUMN BELOW WAYS .................... 13-1/2" INFINITELY VARIABLE SPINDLE SPEEDS ........ 40 TO 250 RPM INFINITELY VARIABLE SPINDLE FEEDS .......... 2 TO 120 SPM GRINDING CAPACITY: GRINDING WHEELS ............................. 3/16" TO 5" DIAMOND MANDRELS ......................... 1/64" TO 3/16" MAIN SPINDLE SLIDE ADJUSTMENT ................ 1-1/2 DEG. EITHER WAY, 3 DEG. INCLUDED ANGLE RADIAL OFF-SET OF GRINDING SPINDLE: (A) - FROM CENTER TO 1-1/8" OFF CENTER BY ROUGH ADJ. (B) - WHILE RUNNING .0001" ADJ. FOR DISTANCE OF .100" ANYWHERE IN THE 1-1/8" RANGE ELECTRICS......220/1 PH APPROXIMATE WEIGHT .......................... 3,700 LBS APPROX. FLOOR SPACE REQUIRED .... 72"LR X 84"FB X 102"H EQUIPPED WITH: 4 HIGH SPEED SPINDLES, 175,000 RPM, 90,000 RPM 60,000 RPM 40,000 RPM ? MANY GRINDING SPINDLES, SETUP FIXTURES, EXTRA SPINDLE BOOT AND COVER. ALL MANUALS, 2 AXIS SCALE AND PLUGS HARDENED, GROUND AND LAPPED STEEL WAYS (NO GIBS) HARDENED, GROUND & LAPPED LEAD SCREWS 1/2 HP VARIABLE DC MOTOR WITH RECTIFIER PRICE LOADED ON YOUR TRUCK,....$14,500.00 SOLD AS IS AS INSPECTED

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	MOORE
MPN	JIG GRINDER
Model	NO. 3
