Motionpro 3+1 Axis Cnc Controller With Usb And Bluetooth Control

US $280

Pune, MH, India
Nov 7th

Open on mobile:
QR code

motionPro is a 3+1 axis CNC controller that can control 4 stepper motors - 3 axis motors plus one clone axis that can be used for X or Y axis. Each motor channel is rated for 2.2A with adequate heatsink (User attachable. Provided in the box.) Say goodbye to parallel ports and ancient computers. This controller can be controlled using a standard USB port or the optional Bluetooth module (module not included with the controller). Here is a quick feature list: 3 + 1 clone axis that can replicate either the X or Y axis (useful for machines with two motors for a single axis) Capable of driving upto 4 NEMA 23 motors at 2.2A per motor (with a heatsink, 1.5A without any heatsink) Full to 1/32 micro-stepping configurable via on board microswitches Current limiting options can be set independently for every axis including the clone axis Options for user configured inputs and feedback such as E-Stop, Reset, Feed Hold, Cycle Start, Homing Location, and Probing (to precisely adjust Z-axis zero set) Accommodates upto 6 limit switches. Limit switches are configurable as active high (normally closed switches) or active low (normally open switches) USB port eliminates ancient parallel ports and freedom from older expensive machines that are hard to get Bluetooth control (with an optional HC-05 bluetooth module) to wirelessly connect and operate the machine Comes with a heatsinks for the motor driver chips Uses standard 18-24V DC supply and with 12V at 1A and 5V at 2A outputs on the board Reverse power connect protection Plenty of visual indicators for debugging Comes pre-installed with grbl v0.9j with default settings. A quick connect guide is included in the box and a comprehensive connection guide is available online here. Watch the controller in action with a laser engraver here. Included in the box: 1 x motionPro controller board 1 x Quick connect guide 4 x heatsinks with thermal pads for the controller driver chips This controller requires an external 12-24V, 3-5A power supply (not included), a USB-B cable and an optional HC-05 Bluetooth module (not included) for wireless control. Since electronic boards and components are static sensitive, improper handling or connecting them in a way they are not intended to will cause failure and damage the board. If you have any queries about this controller or are unsure about certain connections, write to us and we'll help you figure it out. We usually respond within 12 hours.
