Motor Speed Controller With Normal-reverse Transfer Switch Dc 12v-40v New

US $10.89

sz, China
Jan 29th

Open on mobile:
QR code

Motor speed Controller with Normal-Reverse Transfer Switch DC 12V-40V New Description Description: CCM2NJ DC Motor Speed Controller allows controlling both the speed and direction of a DC motor using a Pulse-Width-Modulated (PWM) DC voltage with a Duty Cycle fully adjustable from 10%-100% (both Positive and Negative DC output). The motor speed controller incorporates a high power MOSFET with a heat sink and can easily provide a continuous current of 3A to your DC motor or other DC load. The circuit also includes LED whose brightness varies proportional to the relative speed of the motor therefore giving a visual feedback of the current speed. Main technical parameters: l Input supply voltage: 12V-40VDC(max) l the maximum output power: 120W l the maximum continuous output current :3A; The overload and short circuit protecting current is 5A l PWM frequency 15kHz l Duty Cycle adjustable: 10%-100% l Power-On LED indicator l The positive inversion switch is used to control the direction l The potentiometer with open and closing function. Specifications: l Item size: 70*39*31mm l Net weight: 72g Package: 1*DC Motor Speed Controller Operating instruction: 1.Connect your motor (or DC load) to the motor terminals as indicated on the wiring diagram. 2.Ensure the switch located in the off state and connect a voltage of 10 to 30V DC to the circuit making sure of the correct polarity of the connection. Note that the voltage applied to the motor will be supply voltage applied to the circuit. It is recommended to add an appropriately rated fuse inline with the positive supply in order to protect the circuit from any possible short circuits. 3.You can now control both the speed of the motor through potentiometer. The LED’s brightness will also increase and decrease proportionally to the relative speed of the motor. You also can control the direction of the motor. Positive inversion switch is used to control the motor speed direction. Important Notes An appropriately rated fuse (rated a little higher than the maximum current you expect to draw) is recommended to ensure safe operation. The controller is NOT reverse-polarity protected and will be damaged if connect the supply voltage with wrong polarity. Double check all connections before applying power and always turn off the power supply before making any wiring changes. Payment Payment : (1).We accept PayPal only. (2).We only ship the item to your Paypal address for fast and accurate shipment. If you want to change the address, please add a note when you make the payment. after you have paid. (3).If you are paying through Paypal using eCheck, note that your item can be shipped only after eCheck has cleared. (4).All payments are expected within 7 days after the last winning auction is closed. A non-payment dispute will be opened if full payment is not received. (5).After you have won the auction, an email will be sent to your eBay registered email address. Delivery details Under normal circumstances, United States Buyers'package is expected to be delivered within 9 to 15 business days with tracking. other countries are 18 to 21 business days without tracking(If you need a tracking, please pay additional $3.00 USD and send us ebay/paypal message.). All the items will be dispatched within 1 business day after the payment cleared. Items will arrive in 8-25 business days. The arrival time depends on some factors and different areas. Please confirm address in your Paypal account, and leave your telephone number to ensure you can timely receive your items. Terms of sales In order to protect both buyer and seller, we only accept PAYPAL payment. Your immediate payment is appreciated, and we will leave positive feedback to you once the payment is made. Check payments may delay the processing time because we will only send out the goods until it's cleared by Paypal. About us Welcome to our store! We are a professional worldwide wholesale company, with our own factory located in China. We supply many products including video game, Home & Garden, health & beauty, phone accessories, computers accessories, camera & camcorder, car accessories, flash disk & card, MP3,MP4 & MP5, Clothing accessories, games, toys & hobbies, jewelry, antique & craftwork. High product quality, reasonable prices, excellent customer service and a reliable credit standing is our tenet. Please come back soon and visit us again! We are looking forward to establishing cooperative relationships with you. Please contact us for more information. Thank you for shopping with us! Contact us Our products are of high quality, and we offer 365 days warranty for all items. We offers a No-hassle 30 days exchange (replace) only if your parcel is defective due to manufacturing problem. However, as every sale is final, we appreciate your reconsideration for any return. Thank you again for your business. Any returning, pls inform us first and send back with return ID (given by LD customer service). Engineered for professional eBay sellers!

Condition:

New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...

Country/Region of Manufacture

China
