Motorola 2n3613 Pnp Germanium Power Transistor 40v 15a Case To-3 Nos

US $9.95

Stanton, California, United States
Jul 19th

Open on mobile:
QR code

Motorola 2N3613 PNP Germanium Power Transistor 40V 15A Case TO-3 NOS NEW OLD STOCK LOT 30888 F27 Characteristic Specifications SEMICONDUCTOR MATERIAL GERMANIUM INTERNAL CONFIGURATION JUNCTION CONTACT VOLTAGE RATING IN VOLTS PER CHARACTERISTIC 40.0 MAXIMUM BREAKDOWN VOLTAGE, COLLECTOR-TO-BASE, EMITTER OPEN AND 30.0 MAXIMUM BREAKDOWN VOLTAGE, COLLECTOR-TO-EMITTER, BASE OPEN AND 20.0 MAXIMUM BREAKDOWN VOLTAGE, EMITTER-TO-BASE, COLLECTOR OPEN CURRENT RATING PER CHARACTERISTIC 2.00 AMPERES MAXIMUM BASE CURRENT, DC AND 7.00 AMPERES MAXIMUM COLLECTOR CURRENT, DC POWER RATING PER CHARACTERISTIC 85.0 WATTS MAXIMUM COLLECTOR POWER DISSIPATION MAXIMUM OPERATING TEMP PER MEASUREMENT POINT 125.0 DEG CELSIUS JUNCTION INCLOSURE MATERIAL METAL ELECTRODE INTERNALLY-ELECTRICALLY CONNECTED TO CASE COLLECTOR MOUNTING METHOD UNTHREADED HOLE MOUNTING FACILITY QUANTITY 2 TERMINAL TYPE AND QUANTITY 2 UNINSULATED WIRE LEAD AND 1 CASE OVERALL LENGTH 0.375 INCHES NOMINAL OVERALL DIAMETER 0.875 INCHES MAXIMUM FEATURES PROVIDED HERMETICALLY SEALED CASE SPECIAL FEATURES JUNCTION PATTERN ARRANGEMENT: PNP (NON-CORE DATA) SPECIFICATION/STANDARD DATA 80131-RELEASE4882 PROFESSIONAL/INDUSTRIAL ASSOCIATION SPECIFICATION

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Maximum Collector-Emitter Saturation Voltage	-3 V
Type	PNP
Collector-Emitter Voltage	40 V
Transistor Category	Power Transistor
Maximum Base-Emitter Voltage	-3 V
Maximum DC Collector Current	15 A
Maximum Base-Emitter Saturation Voltage	-2 V
MPN	2N3613
Maximum Collector-Base Voltage	-10 V
Packaging	Case
Number of Pins	2
Brand	Motorola
Series	2N3613
Package/Case	TO-3
