MOTOROLA 2N3734 Bipolar Junction Transistor, NPN Type, TO-5, GOLD LONG LEADS, US $15.95 – Picture 0
MOTOROLA 2N3734 Bipolar Junction Transistor, NPN Type, TO-5, GOLD LONG LEADS, US $15.95 – Picture 0

Motorola 2n3734 Bipolar Junction Transistor, Npn Type, To-5, Gold Long Leads

US $15.95

  • Stanton, California, United States
  • Jul 14th
Open on mobile:
QR code
MOTOROLA 2N3734 Bipolar Junction Transistor, NPN Type, TO-5, GOLD LONG LEADS  NEW OLD STOCK LOT  30865  F27 NSN: 5961-00-401-7503 Name Value INCLOSURE MATERIAL METAL OVERALL LENGTH 0.260 INCHES MAXIMUM TERMINAL LENGTH 1.500 INCHES MINIMUM OVERALL DIAMETER 0.370 INCHES MAXIMUM INTERNAL CONFIGURATION JUNCTION CONTACT JOINT ELECTRONIC DEVICE ENGINEERING COUNCIL/JEDEC/CASE OUTLINE DESIGNATION TO-5 ELECTRODE INTERNALLY-ELECTRICALLY CONNECTED TO CASE COLLECTOR MOUNTING METHOD TERMINAL TERMINAL CIRCLE DIAMETER 0.200 INCHES NOMINAL FEATURES PROVIDED HERMETICALLY SEALED CASE SEMICONDUCTOR MATERIAL SILICON VOLTAGE RATING IN VOLTS PER CHARACTERISTIC 50.0 MAXIMUM BREAKDOWN VOLTAGE, COLLECTOR-TO-BASE, EMITTER OPEN AND 5.0 MAXIMUM EMITTER TO BASE VOLTAGE, STATIC, COLLECTOR OPEN AND 30.0 MAXIMUM BREAKDOWN VOLTAGE, COLLECTOR-TO-EMITTER, BASE OPEN CURRENT RATING PER CHARACTERISTIC 1.50 AMPERES SOURCE CUTOFF CURRENT MAXIMUM POWER RATING PER CHARACTERISTIC 1.0 WATTS SMALL-SIGNAL INPUT POWER, COMMON-COLLECTOR MINIMUM TRANSFER RATIO 120.0 MAXIMUM STATIC FORWARD CURRENT TRANSFER RATIO, COMMON-EMITTER SPECIAL FEATURES JUNCTION PATTERN ARRANGEMENT: NPN TERMINAL TYPE AND QUANTITY 3 UNINSULATED WIRE LEAD
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Mounting Style Through-Hole
MPN 2N3734
Number of Pins 3
Brand Motorola
Series 2N3734
Package/Case TO-5
Type NPN
