Motorola 2n3738 Bipolar Junction Transistor, Npn Type, To-66, Old Gold (1pc)

US $5.95

Stanton, California, United States
Jul 21st

Open on mobile:
QR code

MOTOROLA 2N3738 Bipolar Junction Transistor, NPN Type, TO-66, OLD GOLD (1PC) NEW OLD STOCK LOT 30908 F27 Characteristic Specifications SEMICONDUCTOR MATERIAL SILICON INTERNAL CONFIGURATION JUNCTION CONTACT VOLTAGE RATING IN VOLTS PER CHARACTERISTIC 250.0 MAXIMUM BREAKDOWN VOLTAGE, COLLECTOR-TO-BASE, EMITTER OPEN AND 225.0 MAXIMUM BREAKDOWN VOLTAGE, COLLECTOR-TO-EMITTER, BASE OPEN AND 6.0 MAXIMUM BREAKDOWN VOLTAGE, EMITTER-TO-BASE, COLLECTOR OPEN CURRENT RATING PER CHARACTERISTIC 500.00 MILLIAMPERES MAXIMUM BASE CURRENT, DC AND 250.00 MILLIAMPERES MAXIMUM COLLECTOR CURRENT, DC POWER RATING PER CHARACTERISTIC 20.0 WATTS MAXIMUM COLLECTOR POWER DISSIPATION MAXIMUM OPERATING TEMP PER MEASUREMENT POINT 200.0 DEG CELSIUS JUNCTION INCLOSURE MATERIAL METAL ELECTRODE INTERNALLY-ELECTRICALLY CONNECTED TO CASE COLLECTOR MOUNTING METHOD UNTHREADED HOLE MOUNTING FACILITY QUANTITY 2 TERMINAL TYPE AND QUANTITY 1 CASE AND 2 UNINSULATED WIRE LEAD OVERALL LENGTH 0.340 INCHES MAXIMUM OVERALL DIAMETER 0.620 INCHES MAXIMUM FEATURES PROVIDED HERMETICALLY SEALED CASE SPECIAL FEATURES JUNCTION PATTERN ARRANGEMENT: NPN (NON-CORE DATA) SPECIFICATION/STANDARD DATA 80131-RELEASE5109 PROFESSIONAL/INDUSTRIAL ASSOCIATION SPECIFICATION

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Mounting Style	Through-Hole
MPN	2N3738
Number of Pins	2
Brand	Motorola
Series	2N3738
Package/Case	TO-66
Type	NPN
