Mp2636 Power Booster & Charger Module

US $9.20

Swanton, Vermont, United States
Jul 9th

Open on mobile:
QR code

Description Up to 16V Sustainable Input Voltage 4.5V-to-6V Operation Voltage Range Power Management Function, Integrated Input-Current Limit, Input Voltage Regulation Up to 3.0A Programmable Charge Current The MP2636 Power Booster & Charger Module is highly-integrated, flexible switch-mode battery charger with system power path management, designed for single-cell Liion or Li-Polymer batteries used in a wide range of portable applications. It is really simple to use, once you plug a lipo battery, it will work like a power bank. When there is an external power supply from VIN, it will charge the battery automatically, and the CHG led will light up; when there is no external power, only battery on battery port, the Boost will be ON. Specifications Charge mode input voltage (VIN): 4.5-6.0V Boost mode output voltage (VOUT): 5V Suitable for battery voltage: 4.2V (3.7V lithium battery full of 4.2V) Charge mode Maximum charge current: 2.5A Boost mode Maximum output current: 2.5A Switching frequency: 600KHz Charging mode efficiency:> 90% Boost mode efficiency:> 90% Support battery overcharge protection Temperature protection: more than 150 , automatic power failure Dimensions 35 * 30mm/ 1.38 * 1.18inches Weight: 12g

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	DFRobot
Type	DFRobot
MPN	DFR0446
UPC	Does not apply
