Mpm / Speedline Accuflex 2006 Automatic Screen Printer 2d Under Screen Cleaner

US $34,700.00

Longwood, Florida, United States
Jan 30th

Open on mobile:
QR code

2006 MPM / Speedline Accuflex screen printer Options : Programmable track width Speed enhancement Vacuum wiper with 18" solvent bar Closed Loop programmable squeegee (incudes SPC) 2D Post Print Verification Includes SPC Auto paste dispenser Automatic Tooling Option w/ 48 pins Full set of manuals Machine Specs : Board Handling Maximum Board Size (X x Y) 23" x 20" (584mm x 508mm) Minimum Board Size (X x Y) 3" x 2" (75mm x 50mm) Board Thickness 0.03" to 0.20" including warpage, (0.8mm to 5.0mm) Maximum Board Weight 10 lbs. (4.5kg) Minimum Board Edge Clearance 0.19" (5mm), 0.12" (3mm) - Optional Maximum Underside Clearance 0.59" (15mm) Transport Speed Adjustable Transport Height From Floor 34" - 38 Transport Track Feed Direction Left-to-Right, Right-to-Left, Left-to-Left and Right-to-Right Triple Track Conveyor Lengths 52" (1320mm), 60" (1524mm), 68" (1727mm) Method of Board Hold-Down Positive edge-clamps (front and rear) Method of Board Support Independent, moveable magnetic support pins Print Parameters Maximum Print Area (X x Y) 22" x 19.6" (559mm x 498mm) Snap-off Speed 0.008" - 0.39"/sec, (0.2mm - 10mm/sec) Print Speed 0.2" - 7.87"/sec, (5mm - 200mm/sec) Print Pressure Up to 44 lbs (20 kg) Print Stroke 20" (508mm) Stencil Frame Size 29" x 29" (737mm x 737mm) standard Smaller Frame Accommodations By use of optional Adapters Vison Vision Field-of-View (FOV) 0.40" x 0.40" (10mm x 10mm) Fiducial Types Standard shape fiducials. See SMEMA standards. Camera System Single roving camera module with dual beam optics Repeatabillity Vision Alignment Repeatability +/- 0.001” (+/- 0.025mm) at 6 sigma (Cp greater than or equal to 2.0*) verified with glass plate capability test** Vision Alignment Accuracy +/- 0.001” (+/- 0.025mm) at 6 sigma (Cp greater than or equal to 2.0*) verified with CeTaQ™ CmController™ capability test** Print Deposit Repeatability and Accuracy +/- 0.002” (+/- .050mm) at 6 sigma (Cp greater than or equal to 2.0*) verified with CeTaQ™ CmController™ capability test** Cycle Time Standard Performance 16.2 seconds*** Speed Enhancement Package 12.5 seconds*** Speed Enhancement Package , Triple Track Conveyor System - 11.0 seconds*** Facilities: Power Requirements 110 - 240V, 50/60Hz (+/-10%) Air Supply Requirements **** 5 CFM at 90 psi, Clean Air Supply Height 62" (1575 mm) Depth 57" (1448 mm) Width - Standard Performance 51.7" (1314 mm) Width - High Performance 52" (1320 mm), 60" (1524 mm), 68" (1727 mm)

Condition:	Manufacturer refurbished: An item that has been professionally restored to working order by a manufacturer or manufacturer-approved vendor. This means the product has been inspected, cleaned, and repaired to meet manufacturer specifications and is in excellent condition. This item may or may not be in the original packaging. See the seller’s listing for full details. ...	Brand	MPM Speedline
Country of Manufacture	United States
Model	Accuflex
