Mpu-9150 Gy-9150 Module Three-axis Gyroscope+accelerator+ Digital Electronic E

US $9.11

Shenzhen, China
Jan 29th

Open on mobile:
QR code

MPU-9150 GY-9150 Module Three-axis Gyroscope+Accelerator+ Digital Electronic Compass Description: MPU-9150 GY-9150 Module Three-axis Gyroscope+Accelerator+ Digital Electronic Compass Description: The MPU-9150 is the world’s first 9-axis MotionTracking device designed for the low power, low cost, and high performance requirements of consumer electronics equipment including smartphones, tablets and wearable sensors. And guess what? You get to play with it. This breakout board makes it easy to prototype with the InvenSense MPU-9150 by breaking out all the pins you need to standard 0.1" spaced headers. The board also provides I2C pullup resistors and a solder jumper to switch the I2C address of the device. The MPU-9150 is a System in Package (SiP) that combines two chips: the MPU-6050, which contains a 3-axis gyroscope, 3-axis accelerometer, and an onboard Digital Motion Processor (DMP) capable of processing complex 9-axis MotionFusion algorithms; and the AK8975, a 3-axis digital compass. The part’s integrated 9-axis MotionFusion algorithms access all internal sensors to gather a full set of sensor data. The part is offered in a 4x4x1mm LGA package and is upgrade-compatible with the MPU-6050 integrated 6-axis MotionTracking device, providing a simple upgrade path and making it easy to fit on space constrained boards. Features: Digital-output 9-axis MotionFusion data in rotation matrix, quaternion, Euler Angle, or raw data format Tri-Axis angular rate sensor (gyro) with a sensitivity up to 131 LSBs/dps and a full-scale range of ±250, ±500, ±1000, and ±2000dps Tri-Axis accelerometer with a programmable full scale range of ±2g, ±4g, ±8g and ±16g Tri-axis compass with a full scale range of ±1200µT Reduced settling effects and sensor drift by elimination of board-level cross-axis alignment errors between accelerometer, gyroscope, and compass VDD Supply voltage range of 2.4V–3.46V; VLOGIC of 1.8V±5% or VDD Gyro operating current: 3.6mA (full power, gyro at all rates) Gyro + Accel operating current: 3.8mA (full power, gyro at all rates, accel at 1kHz sample rate) Gyro + Accel + Compass + DMP operating current: 4.25mA (full power, gyro at all rates, accel at 1kHz sample rate, compass at 8Hz rate) Accel low power mode operating current: 10uA at 1Hz, 20uA at 5Hz, 70uA at 20Hz, 140uA at 40Hz Full Chip Idle Mode Supply Current: 8µA 400kHz Fast Mode I?C serial host interface On-chip timing generator with ±1% frequency variation over full temperature range 10,000g shock tolerant I2C Pullup Resistors populated on board. All Pins Broken Out to Standard 0.1" Spaced Headers Solder Jumper for Switching LSB of I2C Address Shipping & Payment: Here Offer 100% Satifiation Service,Inlucde re-send item&refund payment; All items here offer 1 year warranty It is not my Duty for Custom Tax All items will be shipped via int'l air mail(( no tracking number for items under $50), the time normally takes 7-15 business days. may be later arrivel if the item is checked by custom; We only accept paypal payment.
