Mr36w200acaar 200 Amp Panel Ammeter , A&m Model 366

US $30.00

Hamilton, Ohio, United States
Jan 29th

Open on mobile:
QR code

METERMASTER MR36W200ACAAR 200 AMP PANEL AMMETER , A&M MODEL 366. MEASURES 3 1/2" ALL ACROSS FRONT BEZEL. Technical Characteristics ( ILs ) 6625-00-538-9710 MRC Requirement Reply ZZZV III FSC APPLICATION DATA TEST SET,ELECT. EQUIP. ZZZK SPECIFICATION/STANDARD DATA 81349-MIL-M-10304/14 GOVERNMENT SPECIFICATION TEST TEST DATA DOCUMENT 81349-MIL-M-10304 SPECIFICATION STYL STYLE DESIGNATOR C1 ROUND FLUSH MTG STDC SURFACE TREATMENT DOCUMENT AND CLASSIFICATION MIL-F-14072 MIL SPEC ALL TREATMENT RESPONSES SR-1 MANUFACTURERS CODE 81349 SR-1 NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE MIL-M-10304/14 SR-1 DEFINITIVE GOVERNMENT SPEC/STD REFERENCE MR36W200ACAAR SFTT SURFACE TREATMENT ENAMEL SEMIGLOSS NHCF NUCLEAR HARDNESS CRITICAL FEATURE NONHARDENED MATT MATERIAL STEEL FEAT SPECIAL FEATURES RUGGEDIZED FAAZ PHASE SINGLE CTTD CIRCUIT ATTACHMENT METHOD AND QUANTITY 2 SOLDER LUG AND 2 THREADED STUD CTQL MOVEMENT SUSPENSION METHOD JEWEL PIVOT BASE CBBL FEATURES PROVIDED LUMINOUS SCALE MARKING AND MAGNETIC SHIELD AND ZERO ADJUSTER BLSB SCALE SELECTION METHOD TERMINAL BHSX (NON-CORE DATA) CIRCUIT CONSTRUCTION TYPE NONELECTRONIC BHMW MEASUREMENT RANGE 0.0 TO 200.0 AMPERES, AC SINGLE INDICATOR SINGLE RANGE BHDC SCALE GRADUATION TYPE LINEAR SINGLE INDICATOR SINGLE RANGE AXHR MOUNTING FACILITY TYPE AND QUANTITY 3 SCREW AND 3 UNTHREADED HOLE AWZJ POWER SOURCE EXTERNAL ASSS POINTER COLOR BLACK SINGLE INDICATOR SINGLE RANGE AQFY BACKGROUND COLOR WHITE SINGLE INDICATOR SINGLE RANGE AQEC MOVEMENT TYPE MOVING IRON VANE APSW METER BODY DIAMETER BEHIND MOUNTING FLANGE 2.800 INCHES MAXIMUM APST METER DEPTH BEHIND MOUNTING FLANGE 1.660 INCHES MAXIMUM APSN (NON-CORE DATA) PANEL FOR WHICH DESIGNED MAGNETIC OR NONMAGNETIC APPN ACCURACY IN PERCENT -2.0 TO 2.0 AT FULL SCALE SINGLE INDICATOR SINGLE RANGE APMM DIAL SCALE MARKING COLOR BLACK SINGLE INDICATOR SINGLE RANGE ANTG SENSITIVITY RATING 1.0 VOLT-AMPERES ANSY FREQUENCY RESPONSE RANGE 25.000 TO 125.000 HERTZ ANRL MOUNTING ARRANGEMENT STYLE E5 THREE HOLE/STUD BOLT CIRCLE AMQY INSTALLATION DESIGN PANEL AMKD INDICATOR TYPE DIAL W/POINTER AKYN FURNISHED ITEMS AND QUANTITY NUT 7; LOCKWASHER 5; SEAL 1 AFFL MOUNTING BOLT CIRCLE DIAMETER 3.160 INCHES NOMINAL ADZC ENVIRONMENTAL PROTECTION COLD RESISTANT AND HEAT RESISTANT AND SHOCK RESISTANT AND SUBMERSIBLE AND VIBRATION RESISTANT AND WATERTIGHT ADAV OVERALL DIAMETER 3.510 INCHES MAXIMUM ACZB FREQUENCY RATING 60.0 HERTZ NOMINAL ABWG SCALE DIVISION QUANTITY 40 SINGLE INDICATOR SINGLE RANGE ABTB MOUNTING HOLE DIAMETER 0.150 INCHES NOMINAL ABHP OVERALL LENGTH 2.850 INCHES MAXIMUM AAPB DIELECTRIC WITHSTANDING VOLTAGE IN VOLTS 3000.0 AACT CIRCUIT CURRENT FOR WHICH DESIGNED AC
