Ms200 Nibp Simulator Hr Blood Pressure Simulation, Accuracy Tester Monitor Usa

US $1000

Elk Grove Village, Illinois, United States
Aug 25th

Open on mobile:
QR code

Introduction It is a multi - purpose test device for testing NIBP Monitor adopted Oscillometry. Concise and elegant in appearance, easy and convenient to operate, and it can generate the pressure up to 400mmHg (53.3 kPa) by the built-in air pump. With the functions of dynamic BP simulation under several conditions, static pressure calibration, automatic leak test and over-pressure relief test, which can quickly and accurately analyze each performance of NIBP Monitor. Functions 1)Pressure leak test 2)Over-pressure relief test 3)BP simulation under standard condition 4)BP simulation under patient condition 5)BP simulation under arrhythmia condition 6)BP simulation under respiratory interference condition 7)BP simulation of neonate 8)Wrist BP simulation 9)User-defined BP simulation 10)System setting function. 11)The parameters set can be stored. 12)ON/OFF function 13)Dynamic BP simulation Performance BP simulation range: Systolic pressure: 2.7 kPa (20 mmHg) ~ 40.0 kPa (300 mmHg) Diastolic pressure: 1.3kPa (10 mmHg) ~ 33.3 kPa (250mmHg) Pulse volume: 0.1 cc ~ 2.4 cc HR range: 30 bpm ~ 250 bpm; pulse volume > 2.00 cc, maximum HR: 200 bpm HR accuracy: ± 1 bpm (except patient condition, arrhythmia and respiratory disturbance) Under patient condition: Weak pulse, tachycardia, obese, geriatric: ±preset value 1%+1bpm Moderate exercise: ±preset value 1.5%+1bpm Strenuous exercise: ±preset value 3%+1bpm Pressure measurement: Range: 0kPa (0 mmHg) ~ 53.3 kPa (400 mmHg) Resolution: 0.1 kPa, 1 mmHg, 1 cmH2O, 1 inH2O, 0.1 psi Accuracy: 0 kPa (0 mmHg) ~ 40.0 kPa (300 mmHg), ± (0.5 % of reading + 0.1) kPa or ± (0.5% of reading +1) mmHg 40.1 kPa (301 mmHg) ~ 53.3 kPa (400mmHg), ± 2% of reading Pressure leak test Generate a pressure up to 400 mmHg by the built-in air pump. It always displays the peak pressure and the real-time pressure. Leak rate is displayed after 10 seconds. Over-pressure relief test Generate a pressure up to 400 mmHg by the built-in air pump, it displays peak pressure. Pressure source: Output range: 6.7 kPa (50 mmHg) ~ 53.3 kPa(400 mmHg) Resolution: 0.1 kPa, 1 mmHg, 1 cmH2O, 1 inH2O, 0.1 psi Deviation between target pressure and actual pressure: ± 1.3 kPa (± 10 mmHg) in range of 13.3 kPa (100 mmHg) ~ 53.3 kPa (400 mmHg) with a minimum volume of 300 cc Airtightness Total airtigtness: < 0.3 kPa/min (2.25 mmHg/min) under “OFF” state Airtightness of built-in cuff: 0.27 kPa/min (2 mmHg/min) BP simulation preset value configuration table BP simulation BP preset value BP HR Pulse volume Standard BP simulation #1 120/8093 80bpm 0.68cc #2 150/100116 0.65cc #3 200/150166 0.60cc #4 255/195215 0.55cc #5 60/30(40) 0.75cc #6 80/5060 0.71cc #7 100/6576 0.69cc BP simulation under patient condition Healthy heart 120/80(93) 75bpm 0.68cc Weak Pulse 110/80(90) 95bpm 0.50cc Mild Exercise 140/90(106) 120bpm 1.00cc Strenuous Exer 140/90(106) 162bpm 1.40cc Obese 120/80(93) 90bpm 0.50cc Geriatric 150/110(123) 95bpm 0.40cc Tachycardia 120/105(110) 130bpm 0.40cc Bradycardia 120/60(80) 45bpm 1.10cc BP simulation under arrhythmia condition Premature Atrial Contraction1 138/53(81) 80bpm 0.70cc Premature Atrial Contraction2 144/64(90) 83bpm Premature Ventricular Contraction 118/61(80) 83bpm Atrial Fibrillation and PVC 139/72(94) 91bpm BP simulation under respiratory interference condition spontaneous breathing1 138/65(89) 104bpm 0.60cc spontaneous breathing2 149/65(93) 105bpm spontaneous breathing3 112/47(68) 86bpm controlled breathing 132/44(73) 98bpm BP simulation of neonate #1 35/15(22) 120bpm 0.11cc #2 60/30(40) 0.10cc #3 80/50(60) #4 100/70(80) BP simulation of wrist cuff #1 120/80(93) 80bpm 0.50cc #2 160/100(120) #3 80/55(63) User-defined BP simulation[1] - - - - Note[1]Support 9 user-defined BP simulation modes. The following parameters can be defined by users:2.3.1.The value of diastolic pressure should be lower than systolic pressure, pulse volume and HR can not be set to the highest values (e.g., pulse volume 2.00cc, HR: 250 bpm; pulse volume > 2.00cc, HR: 200bpm). Accessories One User Manual Two fuses One power cord Physical characteristic Display: 4.3" 65 K color LCD display Power supply: AC100 ~ 240 V 50/60 Hz, <60 VA Environment temperature: + 5 ~ + 40 Relative humidity: < 90 %, non-condnsing Altitude: 3000 m Atmospheric pressure: 80 kPa ~ 106 kPa Dimension: 270 (L) 265 (W) 132 (H) mm Weight: about 4 kg Buy safe Product The following FDA Disclaimer is required for all eBay listing in Healthcare category and is included for REFERENCE: The sale of this item may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. If the item is subject to FDA regulation, we will verify your status as an authorized purchaser of this item before shipping of the item. The Fingertip Pulse Oximeter is registered on the Australian Register of Therapeutic Goods (ARTG)with the code 197923, and certified by FDA of United States and CE,TUV of Europe. The Fingertip Pulse Oximeter that is FDA 510K Approved Please use under the doctor's instruction Shipping: 1). We will ship within 1 business day after your payement ;ship from China warehouse by China Post 2-4 weeks Arrival 2).We don't add taxes, VAT or other hidden charges. You pay us what you see on the invoice, i.e. goods subtotal + shipping cost (not include duties). Please find out as much as you can about your import taxes in your own country before bidding the item. You need to pay for the import duties in case that occurred for certain goods, or you may kindly give us some suggestions about that, we promise to do our best to help you! About Warranty: We guarantee new equipment other than accessories to be free from defects in workmanship and materials for a period of twelve months (six months for spare parts) from the date of shipment under normal use and service. Our company's obligation under this warranty is limited to repairing, at our company's option, any part which upon our company's examination proves defective. Return Policy: If you receive a defective item which you want to return, please contact us within 5 days from the day you receive the item. All return items must be returned with its original packaging and accessories. If we confirm the damage happened during the shipment, we will bear the shipping cost for return. We will refund the money to you when we get the return items. Or replace item for you free of charge.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	MS200
MPN	69450401
Country/Region of Manufacture	China
Brand	CONTEC
UPC	Does not apply
