#mv-20 Hansvedt 75 Amp Ram-type Cnc Edm Machine (new 2008)

US $24,500.00

Hauppauge, New York, United States
Jan 30th

Open on mobile:
QR code

Model: MV-20 HANSVEDT Ram-Type CNC EDM Machine, S/N: 2467 (New 2008) Specifications: Work tank internal dimensions, L-R x F-B x H Table dimension, L-R x F-B Table travel, longitudinal (X-axis) Table travel, cross (Y-axis) Ram travel (Z-axis) Orbit travel, U-axis Orbit travel, V-axis Minimum/Maximum distance, platen to table Electrode maximum weight Maximum workpiece weight Reservoir capacity 35.5" x 20.5" x 13" 20" x 12" 13" 10" 8" .400" .400" 6.75"/14.75" 33 Lbs. 500 Lbs. 100 US gal Equipped With: M-Pulse 75 amp three-axis (U,V, & Z) CNC control with a menu-based software operating system, 14" CRT, RS-232 port, 3.5" floppy disk drive, and remote control Programmable in the same program M-Pulse (Measured Pulse-produces sparks that are equal in duration) and V-Pulse (Variable Pulse-providing the best cutting rates under poor flushing conditions) operating modes Programmable orbiting/vectoring head with .400" U and V axis travel, orbiting capability to enlarge a cavity or through-hole by an equal amount on each side or on a segment by using circular, vector, or trace vector orbits X & Y axes manually positioned through the use of handwheels Interactive Digital Readout: Allows X and Y positons to be "programmed" from the control. The Work piece displays will change from red to black when a programmed XY move is read by the CNC control. The Work piece display will revert to black when the table is positioned at the program coordinates. Rigid cast iron quill-type ram with 3.375" x 3.25" platen to accept a V-block or precision tooling Precision cast iron XY table with turcite lined dovetail ways High-response DC servo and ballscrew drive High-flow dielectric fluid system with reservoir, pump, and 5 micron filter Programmable DC arc protection #RBH-1C ROTOBORE spindle with assorted size collets 1/2 H.P. 3/60/220-380 volt dielectric pump motor and tank Machine is wired for 3/60/220 volt operation. Approximate Weight: 2,600 Lbs. Location: F.O.B. Truck, Hauppauge - Long Island, NY - We Ship Worldwide Reference #: EDM_GM3229

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	HANSVEDT
Model	MV-20
