Mw Meanwell Lph-18-24 Led Driver 18w 24v Ul Ce Listed Ip67 -new

US $16.19

Wenzhou, Zhejiang, China
Jan 29th

Open on mobile:
QR code

Click Here. Double your traffic. Get Vendio Gallery - Now FREE! Features: 180-264VAC input only Fully encapsulated with IP67 level (Note.5) Protections:Short circuit / Over load / Over voltage / Over temperature Cooling by free air convection Pass LPS 100% full load burn-in test Suitable for LED lighting and moving sign applications High reliability / Low cost 2 years warranty Specification: MODEL:LPH-18-24 DC VOLTAGE:24V CURRENT RANGE:0 ~ 0.75A RATED CURRENT:0.75A RATED POWER:18W RIPPLE & NOISE (max.) Note.2:150mVp-p VOLTAGE TOLERANCE Note.3:3.0% LINE REGULATION:1.0% LOAD REGULATION SETUP, RISE TIME:1500ms, 30ms / 230VAC HOLD UP TIME (Typ.):50ms/230VAC at full load VOLTAGE RANGE:180 ~ 264VAC 254 ~ 370VDC FREQUENCY RANGE:47 ~ 63Hz EFFICIENCY (Typ.):82% AC CURRENT (Typ.):0.3A/230VAC INRUSH CURRENT (Typ.):Cold start 50A/230VAC LEAKAGE CURRENT:0.25mA / 240VAC OVER CURRENT:Above 105% rated output power Protection type : Hiccup mode, recovers automatically after fault condition is removed OVER VOLTAGE:27.6~ 32.4V Protection type : Shut off o/p voltage, clamping by zener diode OVER TEMPERATURE:Tj 170 t ypically (U1) Detect on main control IC Protection type : Hiccup mode, recovers automatically after temperature goes down WORKING TEMP:-30 ~ +70 (Refer to output load derating curve) WORKING HUMIDITY:20 ~ 90% RH non-condensing TEMP. COEFFICIENT:0.03%/ (0 ~ 50 ) VIBRATION:10 ~ 500Hz, 2G 12min./1cycle, period for 60min. each along X, Y, Z axes SAFETY STANDARDS:TUV EN60950-1, IP67 approved; design refer to UL1310 Class 2,EN61347-2-13, CAN/CSA C22.2 No. 223-M91 WITHSTAND VOLTAGE :I/P-O/P:3KVAC ISOLATION RESISTANCE:I/P-O/P:>100M Ohms / 500VDC / 25 / 70% RH EMI CONDUCTION & RADIATION:Compliance to EN55022 (CISPR22) Class B HARMONIC CURRENT:Compliance to EN61000-3-2 Class A, EN61000-3-3 EMS IMMUNITY:Compliance to EN61000-4-2,3,4,5,6,8,11; ENV50204, EN55024,Light industry level,criteria A

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Mean Well
Country/Region of Manufacture	China
Model	LPH-18-24
Country of Manufacture	China
