Mws 2n3897 Silicon Controlled Rectifier,200v V(drm),11a I(t),to-208aa

US $7.95

Stanton, California, United States
Jul 22nd

Open on mobile:
QR code

MWS 2N3897 SILICON CONTROLLED RECTIFIER,200V V(DRM),11A I(T),TO-208AA NEW OLD STOCK LOT 30940 F27 Characteristic Specifications SEMICONDUCTOR MATERIAL SILICON INTERNAL CONFIGURATION JUNCTION CONTACT VOLTAGE RATING IN VOLTS PER CHARACTERISTIC 200.0 MAXIMUM FORWARD VOLTAGE, PEAK AND 200.0 MAXIMUM REPETITIVE PEAK REVERSE VOLTAGE AND 330.0 MAXIMUM REVERSE VOLTAGE, PEAK CURRENT RATING PER CHARACTERISTIC 22.00 AMPERES MAXIMUM AVERAGE FORWARD CURRENT AVERAGED OVER A FULL 60-HZ CYCLE AND 350.00 AMPERES MAXIMUM AVERAGE ON-STATE CURRENT, 180 DEGREES CONDUCTION ANGLE, AVERAGE OVER A FULL 60-HZ CYCLE AND 2.00 AMPERES MAXIMUM FORWARD GATE CURRENT MAXIMUM OPERATING TEMP PER MEASUREMENT POINT 100.0 DEG CELSIUS CASE INCLOSURE MATERIAL METAL ELECTRODE INTERNALLY-ELECTRICALLY CONNECTED TO CASE ANODE MOUNTING METHOD THREADED STUD MOUNTING FACILITY QUANTITY 1 THREAD SERIES DESIGNATOR UNF NOMINAL THREAD SIZE 0.250 INCHES TERMINAL TYPE AND QUANTITY 1 THREADED STUD AND 2 TAB, SOLDER LUG OVERALL LENGTH 1.402 INCHES MAXIMUM OVERALL WIDTH ACROSS FLATS 0.552 INCHES MINIMUM AND 0.562 INCHES MAXIMUM SPECIAL FEATURES JUNCTION PATTERN ARRANGEMENT: PNPN (NON-CORE DATA) SPECIFICATION/STANDARD DATA 80131-RELEASE5169 PROFESSIONAL/INDUSTRIAL ASSOCIATION SPECIFICATION

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Collector-Emitter Voltage	11 V
Maximum DC Collector Current	2 A
Maximum Collector-Base Voltage	200 V
MPN	2N3897
Series	2N3897
Brand	MWS
Type	PNPN
Package/Case	TO
