Narex 0-9" Vhu-36 Universal Boring & Facing Masterhead W/ Cat 40 Shank

US $130

Hamden, Connecticut, United States
Nov 6th

Open on mobile:
QR code

Narex 0-9" Capcity Model No. VHU-36 Universal Boring & Facing Masterhead w/CAT 40 Shank for CNC Mills, Solve All Your Boring & Facing Problems. VHU- as boring device-considerably increases possibilities of boring, drilling and milling machines. These heads are suitable for percision boring of cylindrical holes, and for machining of external cylindrical surfaces. The boring head VHU by means of an automatic slide feed makes possible facing, backfacing and taper machining. The slide fee is adjustable in three or four grades and is stopped on adjustable dog by the pin clutch. The feed is derived from the rotary motion of the head, if one of the feed is adjusted, the pin of the clutch is put in and the brake ring is held by means of the stop bar. The screw serves for quick adjusting of slide and, or the contrary, the worm with the scale is used for find adjusting of precision boring. (1 division = slide movement of 0,005mm.) These heads are delivered with primary accessories in boxes. The taper shank is exchangeable and it is not a component of primary accessories. Therefore it is necessary to order taper shank as seperate items. VHU-36 Universal Boring & Facing Masterhead Operating Accuracy +/- .0002 Boring & Facing Range 0 to 9" Max. adjustability of slide 1.375 Max. dia of slide 2.750 Various automatic slide-feeds per revoluation .0016 .0032 .0048 1 graduation of sensitive adjustments ins. on dia. .0005 1 Revoluation of sensitive adjustment .016 Quick return per revoluation .030 Diameter of tool post holes in slide 5/8 Height of Head without shank 3.125 Width of Head 2.875 Standard Equipment Supplied with The Masterhead In Case Boring Bars 2 Pcs. of 3/8" Boring Bars 2 Pcs. of 5/8" Extension holder 5/8" x 3-7/8" Complete set of reinforcing rings 5/8" Carbide round tool bits 5/8" Reducting sleeve 5/8" x 3/8" Basic Machining Operations Shown Below (Third Images) 1 Boring 2 Facing 3 Internal Recessing 4 Recessing 5 Back facing 6 Machining of external cylindrical surfaces 7 Boring of taper hole 8 Machining of external taper 9 Thread cutting Note: Please call me @ 401-490-1141 for any questions you may have. Quantity discount available. Visit my Free Shipping 10 Reason to bid or buy my listing or products from eBay We do accept world the most secure & reliable payment method “PayPal”. Listings are described with detail information. Every listing or items have digital images from every angle from buyer’s perspective. You will get what we are advertising on eBay no substitute or alternative products. We are not listing anything on eBay, which we do not have in stock so; you will get your won products definitely. Prompt Shipping - As soon as we get the payment we are shipping products as per customer instruction. Prompts Feedback – We left positive feedback as soon as we ship your products, we do not wait for buyers to leave feedback first. So, you have 100% guarantees that you will get the feedback as soon as complete the transactions. We do expect same from buyer for feedback. We do combine all you items to save shipping cost. Every shipping package have tracking # so, it is easy to track. We will e-mail you tracking# as soon as we ship your auctions. 100 % satisfaction guarantee. Great customer service.
