National Instruments Ni At-mio-16x Multifunction Daq I/o Isa Card Board For Scxi

US $98.49

Santa Clara, California, United States
Jan 29th

Open on mobile:
QR code

UP FOR BID: Tektronix OTS91C1 OC192/STM64 CLK/TR Card Board for OTS9010 Optical Test System Working unit. What you see what you get, no other parts are included here is the info from manufacturer: The AT-MIO-16X is a high-performance,software-configurable 16-bit DAQ board for laboratory, test andmeasurement, and data acquisition and control applications. Theboard performs high-accuracy measurements with self-calibration,high-speed settling to 16 bits, noise as low as 0.8 LSBrms, and amaximum DNL of ±0.5 LSB. Because of its large FIFOs anddual-channel DMA, the AT-MIO-16X can achieve high performance,even when used in environments that may have long interrupt latencies,such as Windows.Because off-the-shelf instrumentation amplifiers require 500 µsec andmore to settle to 16-bit accuracy at high gains when sampling multiplechannels, National Instruments developed the NI-PGIA. The NI-PGIA,which is used on the AT-MIO-16X, is an instrumentation amplifier thatsettles to 16 bits in 40 µs, even when the board is used at its highest gainof 100.A common problem with DAQ boards is that you cannot easilysynchronize several measurement functions to a common trigger ortiming event. The AT-MIO-16X has the Real-Time System Integration(RTSI) bus to solve this problem. The RTSIbus consists of our customRTSI bus interface chip and a ribbon cable to route timing and triggersignals between several functions on one or more DAQ boards inyour PC.The AT-MIO-16X can interface to the Signal Conditioning eXtensionsfor Instrumentation (SCXI) system so that you can acquire over 3,000analog signals from thermocouples, RTDs, strain gauges, voltagesources, and current sources. You can also acquire or generate digitsignals for communication and control. SCXI is the instrumentationfront end for plug-in DAQ boards.Analog InputThe AT-MIO-16X is a high-performance multifunction analog, digital,and timing I/O board for the PC. The AT-MIO-16X has a 10 µsec,16-bit, sampling ADC that can monitor a single input channel, or scanthrough the 16 single-ended or 8 differential channels (expandable withNational Instruments multiplexing products) at a programmable gain of1, 2, 5, 10, 20, 50, or 100 for unipolar or bipolar input ranges. A512-word ADC FIFO buffer can perform seamless data acquisition atthe maximum rate without data loss. Internal or external triggering andsampling are supported. If signal conditioning or additional analoginputs are required, you can use the SCXI signal conditioning modules,SCXI multiplexer products, or the AMUX-64T multiplexer board.You can use the NI-DAQ software included with the AT-MIO-16X tocalibrate the analog input circuitry. This software adjusts the offsetand gain errors to zero by means of board-level calibration DACs. Youcan store calibration DAC constants resulting from the calibrationprocedure in the onboard EEPROM for later use. See Chapter 6,Calibration Procedures, for additional information on calibrationprocedures for the AT-MIO-16X.Analog OutputThe AT-MIO-16X also has two deglitched, double-buffered,multiplying, 16-bit DACs that may be configured for a unipolar orbipolar voltage output range. An onboard, +10-V reference is theinternal reference to the circuitry of the DAC. A 2,048-word DAC FIFObuffer allows seamless waveform generation at the maximum ratewithout data loss. The DAC FIFO can perform cyclic waveformgeneration directly from the FIFO, independent of the PC interface.You can use the analog output circuitry for internal timer and externalsignal update capability for waveform generation.You calibrate the analog output circuitry through the NI-DAQ softwareprovided with the board. This software adjusts the DAC offset and gainerrors of each channel to zero by means of board-level calibrationDACs. Calibration DAC constants resulting from the calibrationprocedure may be stored in the onboard EEPROM for later use. SeeChapter 6, Calibration Procedures, for additional information oncalibration procedures for the AT-MIO-16X Warehouse loc: KL-1-3 See actual picture Please Note the following: 1. Free local pick up or you can send your own shipping label 2. If you have any questions regarding this item, please contact me _before_ bidding. -------------------------------------------- Please check SH via shipping calculator. Expedited shipping can be arranged upon request Other Notes of Interest Shipments : All items will ship within 1 business days of payment receipt.

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Working board”
