National Instruments Ni Pxi-6542 32-channel Digital Waveform Generator Analyzer

US $875.00

  • Boise, Idaho, United States
  • Jan 29th
Open on mobile:
QR code
This listing is for one tested and guaranteed functional National Instruments (NI) PXI-6542, 100-Mhz 32 channel deep-memory digital waveform generator/analyzer. The module passes self-test and self-calibration. The unit was manufactured in September 2011. Assembly #191151D-05L and is same unit shown in photos. The module has 8Mbit/channel memory option. From NI- The National Instruments PXI-6542 is a 100 MHz digital waveform generator/analyzer for interfacing to digital electronics. This module features 32 channels with per-channel direction control and deep onboard memory with triggering and pattern sequencing. Through the NI-HSDIO driver, you can configure the module for 5.0, 3.3, 2.5, or 1.8 V logic. You also can use the NI PXI-6542 with the NI Digital Waveform Editor, an interactive software tool for creating and editing digital waveforms. With the SMC, you can create mixed-signal test systems with digitizers, arbitrary waveform generators, and other digital waveform generator/analyzers, or you can synchronize multiple digital devices to build low-skew multichannel systems for interfacing to high-pin-count digital ICs and electronics. Compatibility with 5.0, 3.3, 2.5, and 1.8 V (software-selectable) 32 channels with per-channel direction control 100 MHz maximum clock rate NI Synchronization and Memory Core (SMC) device   The PXI-6542 module will be well packaged and sent in box via USPS Priority Mail. with signature required, insured. The tracking # will be entered into ebay and Paypal systems after shipment.
Condition Used :
An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes “Used PXI module in good working condition- passes self-tests and self-calibration. Has minor cosmetic wear that does not affect function or performance.”
