National Instruments Ni Pxie-1075 Pxie-5644r 2790 5540 Wireless / Gps /rf System

US $700

Chicago, Illinois, United States
Jun 14th

Open on mobile:
QR code

Fully working unit, offered as seen in pictures. 14-Day ROR Last 2 units in stock System includes the following: 2 each NI PXIe-5644R Vector Signal Analyzer 65 MHz - 6.0 GHz (retail from $46,000 to $53,000 each) From Mfr. specs': Vector signal analyzer and generator in a single PXI module Up to 200 MHz instantaneous bandwidth 24 channels of high-speed digital I/O up to 250 Mbit/s Built on FPGA technology programmable with NI LabVIEW software Industry-leading performance and test times for testing the latest wireless standards such as 802.11ac, including optional specifications Easily expands to support multiple input, multiple output (MIMO) configurations or parallel testing in a single PXI chassis 2 each NI PXIe 2790 6 GHz Combiner (retail $2,800 each) From Mfr. specs': Combine and switch signals from 10 MHz to 6 GHz Ideal for multi-DUT cellular and wireless connectivity production test Ability to store RF path calibration information in NI Switch Executive Unlimited switch lifetime 50 ohm termination on channel and COM lines 2 each NI 5540 6 GHz RF Combiner (retail $2,200 each) NI PXIe-8135 2.3 GHz Quad-Core Embedded Controller ($5,900 retail) From Mfr. specs': Intel Core i7 -3610QE quad-core processor (2.3 GHz (base), 3.3 (single-core Turbo Boost)) Up to 8 GB/s system, up to 4 GB/s slot bandwidth 4 GB (1 x 4 GB DIMM) dual-channel 1600 MHz DDR3 standard, 16 GB (2 x 8 GB DIMM) maximum High-performance 7200 rpm integrated hard drive with standard option Six USB ports - 2 SuperSpeed USB, 4 Hi-Speed USB Two 10/100/1000BASE-TX Ethernet ports Other peripherals (GPIB (IEEE 488) controller, RS232 serial port, and IEEE 1284 ECP/EPP parallel port) In-ROM memory and hard drive diagnostics Software - already installed OS and drivers and hard-drive-based recovery image (Windows 7 Pro) NI PXIe-1075 18-Slot 3U PXI Express Chassis with AC - Up to 4 GB/s ($7,400 retail) From Mfr. Specs': Accepts 3U PXI, PXI Express, CompactPCI, and CompactPCI Express modules Up to 1 GB/s per-slot dedicated bandwidth 8 hybrid slots, 8 PXI Express slots, and 1 PXI Express system timing slot Low-jitter internal 10 MHz reference clock for PXI slots with 25 ppm stability Low-jitter internal 100 MHz reference clock for PXI Express slots with 25 ppm stability Quiet operation for 0 to 30 °C at 45 dBA Variable speed fan controller optimizes cooling and acoustic emissions Remote power-inhibit control Complies with PXI and CompactPCI specifications Display port cable Display port to DVI adapter RF sma jumper cables (10 cables) Power cord Keyboard Mouse
