National Instruments Ni Pxie-8115 Pxie-6214 Pxie-4140 Pxi-2567 Pxi-6509

US $1300

Dallas, Texas, United States
Jun 19th

Open on mobile:
QR code

PXIe-1082 8-Slot 3U PXI Express Chassis With AC - Up to 8 GB/s Starting at $ 3,799 Photo is example 4 hybrid slots, 2 PXI Express slots, 1 PXI Express system timing slot 420 W total power available from 0 °C to 55 °C High performance - up to 2 GB/s per slot dedicated bandwidth and 8 GB/s system bandwidth Rugged portable monitor and keyboard, rugged carrying case, and other accessories available Compatibility with PXI, PXI Express, CompactPCI, and CompactPCI Express modules NI PXIe-8115 2.5 GHz Dual-Core PXI Express Controller Starting at $ 5,299 NI recommends the NI PXIe-8840 2.5 GHz dual-core Intel Core i5-2510E processor (3.1 GHz maximum in single-core, Turbo Boost mode) Up to 1 GB/s system bandwidth and 250 MB/s slot bandwidth 2 GB (1 x 2 GB DIMM) single-channel 1333 MHz DDR3 RAM standard, 8 GB maximum Two Gigabit Ethernet, 6 Hi-Speed USB, ExpressCard/34, GPIB, serial, and other peripherals Windows OS and drivers already installed; hard-drive-based recovery NI PXIe-6124 16-Bit, 4 MS/s Simultaneous Sampling Multifunction DAQ Starting at $ 3,914 4 simultaneously sampled analog inputs at 4 MS/s per channel with 16 bits of resolution Analog and digital triggering PXI Express interface for fast, dedicated bandwidth Two 16-bit analog outputs at 4 MS/s single channel, 2.5 MS/s both channels 24 digital I/O lines; two 32-bit counters NI-DAQmx driver software and LabVIEW SignalExpress interactive data-logging software NI PXIe-4140 4-Channel Source Measure Unit (SMU) Starting at $ 5,349 4 SMU channels per single-slot, 3U PXI Express module ±10 V at ±100 mA output with 4-quadrant operation 100 pA current measurement sensitivity Continuous sampling of up to 600 kS/s Onboard hardware sequencing engine for triggering and synchronization NI PXI-2567 64-Channel External Relay Driver Module Starting at $ 1,217 Works with internal or external power sources Provides up to 50 VDC or 600 mA per channel with an external supply High-power protection circuitry IVI-compliant NI-SWITCH driver software Control up to 64 external relays Includes connector and backshell for signal connections NI PXI-6509 Low-Cost, High-Current, 96 Ch, 5 V TTL/CMOS Digital I/O Starting at $ 460 96 bidirectional digital I/O lines, 5 V TTL/CMOS (line direction selectable on an 8-bit port basis) High-current drive (24 mA sink or source) Programmable DO power-up states, DIO watchdogs, change detection, programmable input filters NI-DAQmx software technology for highest productivity and performance (NI-DAQmx 7.1 and later) Low-cost solution with advanced features for manufacturing test and industrial control applications
