National Instruments Pci-5411 High-speed Arbitrary Waveform Generator Card

US $1400

Phoenix, Arizona, United States
Jun 14th

Open on mobile:
QR code

National Instruments PCI-5411 High-Speed Arbitrary Waveform Generator Comes with what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from National Instruments and may vary slightly due to upgrades, options, or revisions this unit may or may not have. This unit is guaranteed to work. The Unit's Information Reads: Model Number: PCI-5411 Serial Number: B567EB Part Number: 183962E-01 Link to the Datasheet: National Instruments PCI & PXI-5122 Digitizer Datasheet Analog Output Specifications: Number of Channels: 1 Resolution: 12 bits Maximum Update Rate: 40 MHz DDS Accumulator: 32 bits Frequency Range: Waveform Type: Arb: 40 MS/s SYNC (TTL): 16 MHz, max Square: 1 MHz, max Ramp: 1 MHz, max Triangle: 1 MHz, max Frequency Resolution (DDS Mode): 9.31 mHz Voltage Output Specifications: Ranges: ±5 V into a 50 Ω load; ±10 V into a high-impedance load Accuracy: ±0.1 dB Output Attenuation: 0 to 73 dB Resolution: 0.001 dB steps Pre-Attenuation Offset: Range: ±2.5 V into 50 Ω1 Accuracy: ± 5 mV Output Coupling: DC Output Impedance: 50 Ω or 75 Ω, software selectable Load Impedance: 50 Ω or greater Output Enable: Software switchable Protection: Short-circuit protected Typical Rise/Fall Time: 8 ns (10-90% 0-5 V square wave into 50 W load, filters off) Sine Spectral Purity: Harmonic Products and Spurs: Up to 1 MHz: -60 dBc Up to 16 MHz: -35 dBc Phase Noise: -105 dBc/Hz at 10 kHz from carrier Notes: 1: With less than 10 dB of attenuation, signal maximum plus offset (before attenuation) must not exceed ±5 V (into 50 Ω). Filter Specifications: Digital: Type: Half-band interpolating Selection: Software switchable (enable or disable) Taps: 67 Filter Coefficients: Fixed 20-bit Data Interpolating Frequency: 2x interpolation (up to 80 MS/s) Pipeline Signal Delay: 26 sampling periods Analog: Type: 7th-order L-C lowpass filter Passband Ripple: ±2 dB Waveform Specifications: Memory: Arb Mode: 2,000,000 16-bit samples DDS Mode: 16,384 16-bit samples Segment Length: Arb Mode: 256 samples, minimum, multiples of 8 samples DDS Mode: 16,384 samples, exact Max Segments in Waveform Memory: 5,000 (Arb mode only) Segment Linking (instruction FIFO): Arb Mode: 292 links DDS Mode: 512 links Segment Looping (Arb Mode Only): Count: 65,536 loops Timing I/O: Update Clock: Internal, 40 MHz, max Interval Count: 2 - 65,535 Phase Locking: Exterenal Reference Sources: Front panel PLL IN SMB connector, internal, or RTSI clock line Reference Clock Frequencies: 1 MHz, 5 - 20 MHz in 1 MHz steps Frequency Locking Range: ±100 ppm Triggers Specifications: Digital Trigger: Compatibility: TTL Response: Rising edge Pulse Width (Td1): 20 ns, minimum Trigger to Waveform Output (Arb Mode) Delay (Td2): 76 sample clocks plus 38 ns, max Trigger to Waveform Output (DDS Mode) Delay (Td2): 28 sample clocks plus 150 ns, max RTSI: Trigger Lines: 7 Clock Lines: 1 Bus Interface Specifications: Type: Slave Operational Modes Specifications: Type: Single, continuous, burst, stepped Other Outputs Specifications: SYNC Out: Level: TTL Duty Cycle: 20 - 80%, software controllable Marker Output: Types: TTL Location: User defined, one per stage Pulse Width (Td4): 8 sample clock periods Arb Output Delay from Marker (Td3): 50 ns, max Digital Pattern Output: Sample Rate: 40 MHz, max Resolution: 16 bits Sample Clock Logic: TTL Clock Pulse HIGH Time: 25 ns, fixed (for clock interval counts > 1) PCLK to Pattern Data Output Time (Tco): 1 ns, max Digital Pattern Logic: TTL Logic Level Output Ratings for SYNC, Marker, Digital Pattern, and Sample Clock Outputs: Type: Min: Max: VOH 3.0 V - VOL - 0.7 V IOH - 1.0 mA IOL - 1.0 mA VOH = voltage output for logic level 1 VOL = voltage output for logic level 0 IOH = current output for logic level 1 IOL = current output for logic level 0 External PLL Reference Input Specifications: Frequency: 1 MHz or 5 - 20 MHz in 1 MHz steps Amplitude: 1 Vpk-pk ≤ level ≤ 5 Vpk-pk Internal Clock Specifications: Frequency: 40 MHz Initial Accuracy: ±5 ppm Temperature Stability (0 to 50°C): ±25 ppm Aging (1 Year): ±5 ppm External Clock Reference Input Specifications: Frequency: 40 MHz, max Amplitude: TTL Mechanical Specifications: Connectors: ARB/Video (Output): SMB/BNC SYNC (Output): SMB/BNC PLL Reference (Input): SMB Digital I/O (Digital Pattern Out, Marker Out, External Trigger In): 50-pin digital, SMB (for PXI, this is PCI) Size: 1 slot Power Requirements: 5 V, 3.5 A, max; 12 V, 125 ma Safety Specifications: Meets the Requirements of the Following Standards for Safety for Electrical Equipment for Measurement, Control, and Laboratory Use: IEC 61010-1, EN 61010-0. UL 61010-1. CAN/CSA C22.2 No. 61010-1 Electromagnetic Compatibility Specifications: Emissions: EN 55011 Class A at 10 M, FCC Part 15A above 1 GHz Immunity: EN 61326:1997 + A2:2001, Table 1 EMC/EMI: CE, C-Tick, and FCC Part 15 CE Compliance Specifications: Meets the Essential Requirements of Applicable European Directives, as amended for CE Markings, as Follows: Low-Voltage Directive (Safety): 73/23/EEC ELectromagnetic Compatibility Directive (EMC): 89/336/EEC For More Pictures Please Click the Following: Picture 2 - Back View Picture 3 - Connector View Picture 4 - Main Unit Serial Number Tag For Domestic Customers: Packaging, handling, and order processing included in shipping in all domestic shipments as quoted by the shipping calculator. For International Customers there is a $15.00 minimum for packaging, handling, and order processing. International shipping to be determined by destination. Prior to shipment I need to know the following information: (1) Are you the end-user of this item? (2) If you are not the ultimate end-user of the item, please state the ultimate end user's name. (3) What is the ultimate country destination? If you have any questions please call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 12/09/15 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
