National Instruments Pci-6602 Daq 8-channel Counter/timer Board

US $450.00

Sterling Heights, Michigan, United States
Jan 29th

Open on mobile:
QR code

National Instruments PCI-6602 DAQ 8-Channel Counter/Timer Board Specifications are from National Instruments and may vary slightly due to upgrades, options, or revisions this unit may or may not have. This item is sold in working condition. Great cosmetic condition as well. The Unit's Information Tags Read: Model Number: PCI-6602 Serial Number: 105DA2E Part Number: 184479F-01 Key Features: 8 up/down, 32-bit counter/timers 80 MHz maximum source frequency (125 MHz with prescalers) Available for PCI computers Can perform three simultaneous high-speed DMA transfers Digital debouncing filters Up to 32 digital I/O lines (5 V/TTL) Power Specifications: Power Requirement: 5 VDC (±5%) NI 6602: 0.5 A to 1.5 A (with 1 m shielded cable as load) varies with application and OCXO warm-up period, does not include I/O power supplied through I/O connector +5 V Power Available at I/O Connector (pin 1): +4.65 V to +5.25 V; 1 A maximum I/O Characteristics: Compatibility: TTL/CMOS Power-on State: Input (high-Z) with weak pull-downs Pull-Down Current: 10 µA min to 200 µA max Input Impedance: 25 k? to 500 k? Output Impedance: 75 ? (56 ? from an onboard resistor and 19 ? from the TIO ASIC) Hysteresis: 300 mV Schmitt triggers Digital Logic Levels Specifications: Input Low Voltage: -0.3 V Min, 0.8 V Max Input High Voltage: 2.0 V Min, Supply + 0.3 V Max Input Low Current (VI = 0 V): -10 µA Max Input High Current (VI = 5 V): 200 µA Max Output Low Voltage (IOL = 4 mA): 0.4 V Max Output High Voltage (IOH = -4 mA): 2.4 V Min. Digital I/O Specifications: Number of Channels: 32 Data Transfer: Static Handshaking: None Timing I/O Specifications: Number of Channels: 8 up/down counter/timers Resolution: 32 bits Maximum Count: 4,294,967,295 Rollover Times: 100 kHz Timebase: 11.93 h 20 MHz Timebase: 214.74 s 80 MHz Timebase: 53.69 s Prescalers: x8 or x2 prescaler for each counter Base Clocks Available: 100 kHz, 20 MHz, and 80 MHz Base Clock Accuracy: 100 ppm (±0.01%) over temperature Maximum Source Frequency: Without Prescaling: 80 MHz With Prescaling: 125 MHz Minimum Edge Seperator (for two edge separation measurement): 2/maximum timebase Data Transfers: DMA (up to 3 channels), interrupts DMA Modes: Scatter-gather RTSI Trigger Lines (PCI Only) Specifications: Trigger Lines <0..6>: 7 RTSI Clock: 1 Minimum Pulse Width for Z index on position measurement: 50 ns Bus Interface Specifications: All Devices: Master, slave Physical Specifications: Dimensions: 16.0 cm x 10.0 cm (6.3" x 3.9") I/O Connector: 68-pin female, SCSI-II type Maximum Working Voltage Speficiations: Channel-to-Earth: ±11 V, Measurement Category I Channel-to-Channel: ±22 V, Measurement Category I Note: Maximum working voltage refers to the signal voltage plus the common-mode voltage. Environment Specifications: Maximum Altitude: 2,000 meters (at 25°C ambient temperature) Pollution Degree: 2 Operating Environment: Ambient Temperature Range: 0°C to 55°C (Tested in accordance with IEC-60068-2-1 and IEC-60068-2-2.) Relative Humidity Range: 0% to 90%, noncondensing (Tested in accordance with IEC-60068-2-56.) Storage Environment: Ambient Temperature Range: -20°C to 70°C (Tested in accordance with IEC-60068-2-1 and IEC-60068-2-2.) Relative Humidity Range: 5% to 95%, noncondensing (Tested in accordance with IEC-60068-2-56.) Safety Specifications: Compliance: IEC 61010-1, EN-61010-1, UL 61010-1, CSA 61010-1 Note: This product meets the requirements of the following standards of safety for electrical equipment for measurement, control and laboratory use. Electromagnetic Compatibility Specifications: EN 61326 (IEC 61326): Class A emissions; Basic immunity EN 55011 (CISPR 11): Group 1, Class A emissions AS/NZS CISPR II: Group 1, Class A emissions FCC 47 CFR Part 15B: Class A emissions ICES-001: Class A emissions CE Compliance Specifications: Compliance: 2006/95/EC; Low-Voltage Directive (safety), 2004/108/EC; Electromagnetic Compatibility Directive (EMC) Posted with eBay Mobile
