Ncv7729 Stepper + Dc Motor Controller 8a H-bridge, Logic 18v Able Ncv7729bppr2g-

US $41

Valley Stream, New York, United States
Jan 29th

Open on mobile:
QR code

NCV7729BPPR2G Stepper + DC motor controller 8A H-bridge, logic 18V tolerant Case: SOIC20 wide METAL PLATE Lot Size: 1 units See other listings and lot sizes for this item See other motor drivers The NCV7729 is an intelligent, fully protected H-Bridge Driver designed specifically for control of DC and stepper motors in safety critical applications under automotive/industrial environment. * Operating VS Battery Supply Voltage 5 V to 28 V * Operation is maintained during automotive cranking * Operating VCC Supply Voltage 3.0 to 5.5 V * Interfaces well with most automotive microprocessors * 18 V Survivability on VCC and All Logic I/O Pins * Protects against regulator failure * Typical RDS(ON) = 150 m?, RDS(MAX) = 300 m?(150C) * Low conduction losses * Selectable Output Current Limitation (2.5 A to 9.6 A) * Wide load range capability * Continuous DC Load Current 5A (TC < 100 °C) * Sustained motor torque * Short-Circuit Protection and Thermal Shutdown * Protects against system faults * Monitoring of All Supply Voltages, Loss of GND Detection * Safe Power-up State * Regulated Charge Pump * Optimized EMI behavior * Output Switching Frequency Up to 30 kHz * Reduces audible noise * Undervoltage Lockout * Prevents spurious drive at low voltage * SPI Interface for Configuration and Diagnosis Datasheet I only ship to buyer's EBAY shipping address IMPORTANT: Buyer controls combining of order, by making a single payment for all items. Multiple payments void any shipping discounts. Can only combine BEFORE payment, never after. How to combine orders. If you have ANY time constraints, contact seller BEFORE buying or bidding, so we can BOTH come to an agreement. INTERNATIONAL shipments will NOT have online tracking , unless you use REGISTERED MAIL -- contact seller for invoice. INTERNATIONAL transit time can be 6-28 business days, and can be delayed by local Customs backlogs. If this is not acceptable, we cannot not enter into any trade. US shipments can take 5-7 business days - however the USPS does NOT guarantee these transit times, and can exceed them. eBay tracking info has 24-48 hrs update latency and can only guarantee a delivery scan -- interim scans may not occur. ALL items shipped to buyer's Registered eBay shipping address address, without exception. We can never take an address from email. Payment closes order. No changes are possible once paid. We have no expedited shipping service outside USA -- If urgent, please source locally. International : If you want seller to be responsible for package in transit , you must choose Registered mail - adds $13 to S&H - contact seller for invoice. supreme supremewidgets supremeauctiononlinesoftware.widgets.EbayGalleryZ.swf supremewidgets supremeauctiononlinesoftware.widgets.GalleryCat.swf supremewidgets supremeauctiononlinesoftware.widgets.FeedbackWidgetBasic.swf
