New 1-500MHZ Reflection Bridge VSWR Bridge RF Bridge Directional Bridge, US $1500 – Picture 0
New 1-500MHZ Reflection Bridge VSWR Bridge RF Bridge Directional Bridge, US $1500 – Picture 0

New 1-500mhz Reflection Bridge Vswr Bridge Rf Bridge Directional Bridge

US $1500

  • Hongkong, Hong Kong
  • Jun 9th
Open on mobile:
QR code
New 1-500MHZ Reflection Bridge  VSWR Bridge RF Bridge Directional Bridge Description: The bridge is a sensor measuring the reflection coefficient for the RF network measurement, the reflected signal that is output from the amplitude phase information as well as the size, with a wide frequency range, high directivity characteristic. The bridge is a simple application can be combined with RF spectrum analyzer or scanner to track the source of the tape, you can measure the return loss and reflection of the entire frequency band of the device; if combined with vector voltmeter or vector voltage measuring device can accurately measure the applied signal source vector impedance circuit, complete RF matching circuit testing and debugging. Widely used in antenna measurements debugging, RF circuits and radio, television and communications equipment and other measurement and debugging. Features: Model: AYT-3 Frequency Range: 1MHZ~500MHZ The Characteristic Impedance: 50? Direction: >=36dB Maximum Input Power:
