New 100pcs Apa104 Replace Ws2812b Chip Bead 5050 Rgb Led Individual Addressable

US $93

CN, China
Jan 29th

Open on mobile:
QR code

New 100PCS APA104 Replace WS2812B Chip Bead 5050 RGB LED Individual Addressable Fullcolor Products: NEW Model: 5050RGB APA104 Input voltage: DC5V Wave length(NM):R-650nm, G-520nm,B-460nm Power::0.24W/PC Signal:APA104 chip View angle:120 degree Life span:no less than 50000hrs Features and Benefits l Intelligent reverse connect protection, the power supply reverse connection does not damage the IC. l The control circuit and the LED share the only power source. l Control circuit and RGB chip are integrated in a package of 5050 components, form a complete control of pixel point. l Built-in signal reshaping circuit, after wave reshaping to the next driver, ensure wave-form distortion not accumulate. l Built-in electric reset circuit and power lost reset circuit. l Each pixel of the three primary color can achieve 256 brightness display, completed 16777216 color full color display, and scan frequency not less than 400Hz/s. l Cascading port transmission signal by single line. l Any two point the distance more than 5m transmission signal without any increase circuit. l When the refresh rate is 30fps, cascade number are not less than1024 points. l Send data at speeds of 800Kbps. l The color of the light were highly consistent, cost-effective.. Applications l Full-color module, Full color soft lights a lamp strip. l LED decorative lighting, Indoor/outdoor LED video irregular screen. General description APA104 is a intelligent control LED light source that the control circuit and RGB chip are integrated in a package of 5050 components. It internal include intelligent digital port data latch and signal reshaping amplification drive circuit. Also include a precision internal oscillator and a 12V voltage programmable constant curre-nt control part, effectively ensuring the pixel point light color height consistent. The data transfer protocol use single NZR communication mode. After the pixel power-on reset, the DIN port receive data from controller, the first pixel collect initial 24bit data then sent to the internal data latch, the other data which reshaping by the internal signal reshaping amplification circuit sent to the next cascade pixel through the DO port. After transmission for each pixel?the signal to reduce 24bit. pixel adopt auto resha-ping transmit technology, making the pixel cascade number is not limited the signal transmission, only depend on the speed of signal transmission. LED with low driving voltage, environmental protection and energy saving, high brightness, scattering angle is large, good consistency, low power, long life and other advantages. The control chip integrated in LED above becoming more simple circuit, small volume, convenient installation. Package include: 100PCS APA104 LED Chips Shipping Detail Delivery to US: USPS First Class Airmail 7-12 Work days Tracking number available Delivery to Others: HK Post Airmail 11-25 Work Days Tracking number available If you do not receive your winning item (s) by 35 business days,Please feel free to contact us through ebay mail system or E-mail, we will try our very best to resolve any problems with you. Payment Method We accept only PayPal payment. A non-payment dispute will be opened if full payment is not received after 14 days of auction. inkfrog terapeak i000000
