New 3.5" Tft Lcd Touch Screen Module 320*480 Rgb Display Board For Raspberry Pi

US $25.80

Shen Zhen, China
Mar 8th

Open on mobile:
QR code

New 3.5" TFT LCD Touch Screen Module 320*480 RGB Display Board For Raspberry Pi Designed for Raspberry Pi Model B/B+, an ideal alternative solution for HDMI monitor 320×480 resolution, better display Convenient Men-Machine interface for Raspberry Pi, combined with the portable power, DIY anywhere anytime Supports Raspbian system, enables your system to: Play videos (supports multi formats, MP4 and so on) Take photos by touching (up to 17 camera modes) Support software keyboard (system interaction without keyboard/mouse) Key Parameters LCD Type TFT LCD Interface SPI Touch Screen Type Resistive Touch Screen Controller XPT2046 Colors 65536 Backlight LED Resolution 320*480 (Pixel) Aspect Ratio 2:3 Power Consumption TBD Backlight Current TBD Operating Temp. (°C) TBD Interface PIN NO. SYMBOL DESCRIPTION 1, 17 3.3V Power positive (3.3V power input) 2, 4 5V Power positive (5V power input) 3, 5, 7, 8, 10, 12, 13, 15, 16 NC NC 6, 9, 14, 20, 25 GND Ground 11 TP_IRQ Touch Panel interrupt, low level while the Touch Panel detects touching 18 LCD_RS Instruction/Data Register selection 19 LCD_SI / TP_SI SPI data input of LCD/Touch Panel 21 TP_SO SPI data output of Touch Panel 22 RST Reset 23 LCD_SCK / TP_SCK SPI clock of LCD/Touch Panel 24 LCD_CS LCD chip selection, low active 26 TP_CS Touch Panel chip selection, low active Package include: 1 x New 3.5" TFT LCD Touch Screen Module 320*480 RGB Display Board For Raspberry Pi We accept PayPal only. 1.Items are shipped from china.we will send out within 1 bussiness day after receive the payment. 2.We only ship to ebay confirmed address. So before bidding, please kindly verify your ebay address. 3.Shipping to USA takes 8-18 days in normal condition by E-packet with tracking number. Shipping to most other countries takes about 12-30 days via Economy Int'l Airmail. Less than $40, without tracking number,if you request tracking number,please pay $3 more and let me know. Over $40,with tracking number free.The shipping time depends on your location and local postal service,as well as the weather condition along the shipping,sometimes may take longer,.please contact us to confirm before leave feedback or open case. 4.Express shipping: Extra $20 --$25 will be charged for the first 500 grams for most countries. Contact us if you need this service. 1.If you are not satisfied when you receive your item, please return it within 30 days for a replacement or money back. Please contact us before you return it. 2.If item is defective in 30 days, We will send you a replacement without extra charger, or offer refund after we receive the defective item. 3.If item is defective after 30 days, you can still send it back to us. We will send you a new one after receiving the defective item. But you have to pay the extra shipping fee. We are honest seller and do our best to serve you. So if you have any concerns,please don’t hesitate to contact us by ebay message. We will do your best to help you out.please don’t leave negative/ neutral feedback or open case before contact us. On Mar-07-15 at 19:21:41 PST, seller added the following information:
