New Abb Af26z-30-00-21 (1sbl236001r2100) Contactor 11kw 400v Coil 24-60v 50/60hz

US $64.99

Vilnius, Lithuania
Jan 29th

Open on mobile:
QR code

AF26Z-30-00-21 General Information Extended Product Type: AF26Z-30-00-21 Product ID: 1SBL236001R2100 EAN: 3471523114111 Catalog Description: AF26Z-30-00-21 24-60V50/60HZ 20-60VDC Contactor Long Description: AF26Z contactors are used for controlling power circuits up to 690 V AC and 220 V DC. They are mainly used for controlling 3-phase motors, non-inductive or slightly inductive loads. AF..Z contactors include an electronic coil interface accepting a wide control voltage Uc min. ... Uc max. Only four coils cover control voltages between 24...250 V 50/60 Hz or 12...250 V DC. AF..Z contactors can manage large control voltage variations. One coil can be used for different control voltages used worldwide without any coil change. AF..Z contactors allow direct control by PLC-output >= 24 V DC 500 mA and obtain a reduced holding coil consumption. AF..Z contactors withstand short voltage dips and voltage sags (SEMI F47-0706 compliance) between 24...250 V 50/60 Hz AF..Z contactors have built-in surge protection and do not require additional surge suppressors The AF... series 1-stack 3-pole contactors are of the block type design. - Main poles and auxiliary contact blocks: 3 main poles, front and side-mounted add-on auxiliary contact blocks. (mechanically-linked auxiliary contacts compliant with Annex L of IEC 60947-5-1. N.C. mirror contacts compliant with Annex F of IEC 60947-4-1) - Control circuit: AC or DC operated - Accessories: a wide range of accessories is available. Dimensions Product Net Width: 45.0 mm Product Net Depth: 86.0 mm Product Net Height: 86.0 mm Product Net Weight: 0.350 kg Environmental Ambient Air Temperature: Close to Contactor for Storage -60...+80 °C Close to Contactor Fitted with Thermal O/L Relay -25...+60 °C Close to Contactor without Thermal O/L Relay -40...+70 °C Maximum Operating Altitude Permissible: 3000 m Resistance to Shock acc. to IEC 60068-2-27: Closed, Shock Direction: B1 25 g Open, Shock Direction: B1 5 g Shock Direction: A 30 g Shock Direction: B2 15 g Shock Direction: C1 25 g Shock Direction: C2 25 g Resistance to Vibrations acc. to IEC 60068-2-6: 5...300 Hz 4 g closed position / 2 g open position RoHS Status: Planned to follow EU Directive 2002/95/EC August 18, 2005 and amendment after 2008 Q1 Technical Rated Operational Power AC-3 (Pe): (220 / 230 / 240V) 6.5 kW (380 / 400V) 11 kW (415V) 11 kW (440V) 15 kW (500V) 15 kW (690V) 15 kW Rated Operational Current AC-1 (Ie): (690V) 40°C 45 A (690V) 60°C 40 A (690V) 70°C 32 A Number of Main Contacts NO: 3 Number of Main Contacts NC: 0 Number of Auxiliary Contacts NO: 0 Number of Auxiliary Contacts NC: 0 Rated Control Circuit Voltage (Uc): 50 Hz 24...60 V 60 Hz 24...60 V DC Operation 20...60 V Terminal Type: Screw Terminals

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	ABB
Country of Manufacture	France
Model	AF26Z-30-00-21
