New Amplifier Board Mp3 Decoder Board Dual-channel Stereo 10w * 10w + Remote

US $9.90

ShenZhen City, China
Jan 29th

Open on mobile:
QR code

Description New Amplifier Board MP3 decoder board Dual-channel stereo 10W * 10W + Remote Specification: Introduce MP3 decoding from the power of dual decoding AT2300 amplifier part of the original PAM8610 chip, PAM8610 chip class-D stereo audio amplifier 10W (each channel). High-quality voice reproduction function, low THD + N (0.1%) non-filter, a very good PSRR, new direct output to drive speakers without low-pass filter. 10V power supply into an 8? load with 10% THD 10W. Filter, low quiescent current, ultra-low EMI, with the shutdown / mute noise cancellation. 90% of the high efficiency, low noise output of-90dB, the working voltage of-13.5V, low THD + N, and low quiescent current, low-power, low heat. With the flow / temperature / short circuit protection. Feature 1. Power: DC 7.5V-12V Static current: 50MA, Maximum operating current: 2A. 2. Output power: Dual-channel stereo 10W * 10W 3. Play: Support: USB, SD card to play songs MP3, WMV music formats, the red light indicator. When inserted U disk, SD card, instructions will flashes. without U-Disk, SD card, the light on not flashes. Means Board work normal. 4. Adjust the volume: Clockwise rotation Means V+. Counterclockwise rotation means V-. 5 Audio input: one end of the dual-channel audio signal line inserted into the machine's audio input jack; the other end inserted into the output socket of an external audio device (for example, MP3 computer. Phone, etc.). When not plugged into an external audio signal to play the songs of the machine. When insert external audio signal, automatically disconnect the USB / SD card. 6 Function keys: the machine on the SD card / USB conversion button on a pause. Under a .USB / SD conversion. EQ(Show as the picture) 7 Remote support for audio input volume ajustment. 8. Support track play, shut off the main power, the next start playing from the last track played. 9. 32-320KBPS rate, to support large-capacity U disk, SD card 10 support the PUSH pop-up-the PUSH longer SD card. 11.PCB Size: 65 * 53mm Application: Mobile audio, home Film, electric cars, motorcycles, car Package Including New Amplifier Board x1pcs Remote Control x 1pcs Recommended Products *****************Similar Product 2pcs x The new speaker 8? 0.5W mini speaker Diameter 36mm Thickness 5MM $2.49 Time Left:11d 18h 42m LM386 Chip 20 Gain Audio Amplifier Module $3.25 Time Left:29d 22h 04m 1pcs Mini Amplifier Board 3W+3W USB Power Supply DC 5V Free shipping $3.45 Time Left:13d 01h 58m LM386 Chip 200 Gain Audio Amplifier Module $4.25 Time Left:28d 22h 46m 1pcs 10W Mini HIFI 12V Digital power amplifier Stereo High power amplifier Board $6.45 Time Left:28d 00h 59m New Amplifier Board MP3 decoder board Dual-channel stereo 10W " 10W + Remote $9.90 Time Left:13d 04h 06m TA2024 digital amplifier board Car PC HIFI amplifier board mini amplifier $9.99 Time Left:21d 03h 09m 4pcs x LM386 Chip 20 Gain Audio Amplifier Module $9.99 Time Left:29d 09h 19m 5pcs Mini Amplifier Board 3W+3W USB Power Supply DC 5V Free shipping $10.99 Time Left:13d 01h 55m BF052 subwoofer Low-pass filter circuit Kit $19.99 Time Left:5d 18h 40m 4pcs 10W Mini HIFI 12V Digital power amplifier Stereo High power amplifier Board $22.99 Time Left:4d 00h 05m HP-500 Car amplifier boost 2V switching power board 500W protected DC converter $41.99 Time Left:5d 22h 59m IRAUD200 Standard D digital amplifier finished board IRS2092S 500W high-power $53.99 Time Left:5d 01h 08m IRAUD350 top D amplifier high power 700W IRS2092S digital power amplifier board $59.90 Time Left:5d 02h 10m IRAUD200 Deluxe top D digital amplifier finished board IRS2092S 500W high-power $59.99 Time Left:5d 00h 15m A30 High current FET Pure Class A amplifier kit Amplifier board $59.99 Time Left:5d 19h 11m MT-68 Desktop amplifier board finished board 130WX2 Effect spike LM3886 TDA7294 $63.99 Time Left:4d 23h 02m 10pcs x Amplifier Board MP3 decoder board Dual-channel stereo 10W " 10W + Remote $89.99 Time Left:11d 00h 15m PR-800 Professional stage amplifier refined board 1000W super high-power $89.99 Time Left:4d 20h 21m Visit my eBay Store: worldwindow2010 Check out my other items! Payment We accept Paypal only, It is fast, Easy and Safe. Payment must be completed within 7 days. PLEASE NOTE: S&H DOES NOT INCLUDE DUTIES, LOCATL TAXES OR ANY OTHER IMPORTATION FEES. Please list your special requests (color, packages, etc.) in the PAYPAL NOTES SECTION when you make payment. Shipping We Ship to Worldwide. Orders processed within 24-48 hours of payment verification. We only ship to confirmed PAYPAL addresses. Your PAYPAL address MUST MATCH your Shipping address. Items will be marked as " Gift " in low value. Items are shipped via China Post & Hong Kong Post & Singapore Post Air Mail. Country Shipping Way Shipping Time Tracking Number United States EUB 7-12 Yes Other Country China/Hong Kong/Singapore Post Air Mail 15-35 No Warranty and Guarantee Good Good quality. Buy with confidence! If you are not satisfied when you receive your item, please return it within 7 days for a replacement or money back. Please contact me before you return it. Not accept returning of electronic components. Full refund after we receive our original item, Note: Return shipping is to be paid by the Buyer. We maintain high standards of excellence and strive for 100% customer satisfaction! Feedback is very important to us. We request that you contact us immediately BEFORE you give us neutral or negative feedback, so that we can satisfactorily address your concerns. Contact Us We strive to provide you with the best service, We will reply your question within 24 hours. Our goal is customer satisfaction! Our Working-time From 8:30 AM to 21:30 PM. you can check our working time from the World-time table. Notice of Shipping: All the item Shipping to USA with tracking number and supply Combined shipping discounts!(eg: If you buy 10 Different types product, Only Charge Shipping fee 1.5usd one-time.) For Worldwide(Except USA): Supply 3 kinds Shipping way and Combined shipping discounts 1), Economy Int'l Shipping Free Shipping(without tracking number)(if the total price is over 20usd also can supply tracking number); 2), Standard Int'l Shipping: 3usd (with tracking Number) 3), Expedited Int'l Shipping: 25usd ( Shipped by DHL/EMS ect.) For example: If you buy some different products(Add to a Card), Only pay 25usd for one product, The other products you can choose free shipping, and then I will send them in one package by DHL/EMS. inkfrog terapeak i000000 inkFrog Analytics
