New Avr Mx321 Automatic Voltage Regulator For Generator And Genset Au1

AU $135.00

CN,CN, China
Jan 30th

Open on mobile:
QR code

Specification SENSING INPUT Voltage 190-264V ac max, 2 or 3 phase Frequency 50-60HZ nominal POWER INPUT Voltage 170-220 V ac max, 3 phase,3 wire CURRENT: 3A/phase Frequency 100-120HZ nominal OUTPUT Voltage max 120V dc Current continuous 3.7A dc Intermittent 6A for 10 secs Resistance 15 ohms minimum REGULATION +/-0.5% RMS with 4% engine goverming THERMAL DRIFT 0.02% per deg.C change in AVR ambient TYPICAL SYSTEM RESPONSE AVR respone 10ms Filed current to 90% 80ms Machine Volts to 97% 300ms EXTERNAL VOLTAGE ADJUSTMENT +/-10% with 5k ohm 1 watt trimmer UNDER FREQUENCY PROTECTION Set point 95%HZ Slope 100% -300% down to 30HZ Max dwell 20% volts/S recoverey UNIT POWER DISSIPATION 18 watts maximum ANALOGUE INPUT Maximum input +/-5V dc Sensitivity 1V for 5% Generator Volts(adjustable) Input resistance 1k ohm QUADRATURE DROOP INPUT 10 ohms burden Max.sensitivity:0.22A for 5% droop OPF Max.input:0.33A CURRENT LIMIT INPUT 10 ohms burden Sensitivity range:0.5-1A OVER VOLTAGE DETECTOR INPUT Set point:300V,time delay:1 sec CB trip coil volts:10-30 vdc CB trip coil RESISTANCE:20-60 ohms OVER EXCITATION PROTECTION Set point:75vdc Time relay:8-15 sec Environmental Vibration 20-100HZ 50mm/sec 100Hz 2kHz 3.3g Operating temperature -40 to +70 C Relative Humidity 0-70C 95% Storage temperature -55 to +80 C Note:Ship many country! Please inquire us for the actual freight to your location. Post Code is required! A phone number is required for the smoothly delivery of your goods! Combined purchase is welcomed! We accept 1.Bank transfer 2.PayPal www.paypal.com 3.the customers want use a Credit Card or Debit Card, who can also make a payment via above two methods. One fee for all We use the handling charge to cover all our shipping department cost, i.e. carriers fee, packaging materials, fuel charges, boxes, and labels.For many countries the shipping fee are vary, you need contact us to confirm the shipping cost. No Local pickup for auction customers. No third party shipping carrier will be used. 2. When you receive your order Your items will be shipped in 1-3 working days after your payment is cleared. The shipping time is 4-5 working days. For some small products which shipping fee is less 20USD, we choose Airmail for the delivery which will take 10 days or 14 days to arrive. sometimes take a little longer, Due to Local dispatch Or other reasons. 1. Multiple purchases saving plan: Please make sure single payment for each item you won. We will combine the shipping when you make multiple purchases. 2. Correct and sufficient corresponding information: Please attached your telephone number when you payment so that we can post your package safety and smoothly. Always make sure provide sufficient information to help us make a smoothly delivery. 1.Return package must be in the original packaging, everything must be in new condition.Missing part’s or anything in original condition, it will not qualify for any refund. We will provide the relevent information to the Ebay and Paypal,such as the shippers' confirmation and products photos 2.Replacement and refunds will not be processed until the return item received. Within warranty period, all exchanges or repairment due to defects are free (Buyer is responsible for shipping charges). We alway care about you our valued customer, please feel free to contact us via MSN: sonic2009r@hotmail.com . Your satisfaction is our goal. Powered by eBay Turbo Lister
