BGA Rework Station T-890 NOTE: we don't ship the item to PO BOX address, and we only ship the item to English address, s please leave us your physical English address when you pay. Features: 1. This machine has the strong and perfect function selection, with eight temperature waves in the memory software, you can select the right temperature wave according to the solder/unsolder request. 2. Intelligent temperature wave heating, can achieve the solder/unsolder automatically. 3. Three-dimensional adjustable lamp body, use laser light, suitable for unsoldering any-angle components. 4. PID intelligent temperature control can avoid the IC damage due to the fast or uninterrupted warming up. 5. This machine has a super hot melt system, use infrared welding technology which is developed independently, heat is easy to pierce and distribute evenly, can suit for a variety of computer, notebook, play station’s BGA components, especially suits to the computer north and south bridge. 6. Friendly human-machine operation interface, perfect LCD display, you can watch the whole repairing process very clearly. 7. Ergonomic design, practical and easily operated. Good build quality but at the same time light weight and a small footprint allows the T-890 to be easily bench positioned, transported or stored. Technical parameters Complete machine power 1500W Rated voltage and frequency AC 110-230 V 60/50Hz Infrared lamp body power 300 W Preheating chassis power 1200 W Working bench size 320 X 330 mm Infrared lamp body heating size 60 X 60 mm Preheating chassis preheating size 245 X 260 mm Preheating chassis temperature range 0 °C-350 °C Size 316mm X 410mm X 290mm Net weight 9.3 kg Main parts Welding table main body 1 Infrared lamp body 1 Portal frame 2 Power line 1 User manual(Compact disc) 1 Operating Instructions: 1. Examination and operation 1). Place this machine on an even surface with good ventilation and no combustible items nearby. Leave at least 20mm on either side because the machine will emit heat when in use. Check the power supply voltage, connect the machine with the power supply, assemble the temp-sensor and infrared lamp, turn on the power switch, the LCD screen will display as follows: Main menu page 2) Press “F1” button, the preheating chassis starts to work, press “F1” button again to stop. 3) Press “F2” button, the infrared lamp starts to work, press “F2” button again to stop. 2. The wave selection and setting 1). Press “F3” button enters to the select/set page, firstly, set the preheating chassis preheat temperature (e.g. set the preheating temperature 113 degree), press “F3/F4” buttons up and down to select different temperature, press “F1” button to save. When hear the tick- tock, it is saved successfully. 2). Press “F2” button enters to the select/set wave page. 3). Press “F2” button enters to the select/set page, following we provide eight different wave cycles, please choose one according to your request, press “F1” to confirm the wave you choose, press “F3” button, come to the Main Menu page. 4). Press “F2” button, the lamp starts heating up according to the setting temperature. 5). When the process finished, return the previous page automatic. If you want to stop in the process, press “F2” button. 3. The wave selection and setting 1). Press “F3” button enters to the select/set page, firstly, set the preheating chassis preheat temperature (e.g. set the preheating temperature 113 degree), press “F3/F4” buttons up and down to select different temperature, press “F1” button to save. 2). Press “F2” button enters to the select/set page. 3). Press “F2” button enters to the select/set page, following we provide eight different wave cycles, please choose one according to your request. 4). If you want to reset the wave, press “F4” to select the point you want to reset, press “F5” button, when it flicker the grid, you can set. Press “F3/F4” buttons up and down to select different temperature, press “F1/F2” buttons forward and backward to select different time, press “F5” button to save.(the grid disappear, change to the previous flicker status), press “F4” button come to next segment, the same method to set the wave, press “F1” button to save the current wave, press “F3” back to the main operation page, the wave setting completed. 5). Press “F2” button, the lamp starts heating up according to the setting temperature. 4. Each temperature wave purposes as follows: Wave one: use the same with soldering the less lead paste, like 85Sn/15Pb 70Sn/30Pb Wave two: use the same with unsoldering the less lead paste, like 85Sn/15Pb 70Sn/30Pb Wave three: use the same with soldering the more lead paste, like 63Sn/37Pb 60Sn/40Pb. Wave four: use the same with unsoldering the more lead paste, like 63Sn/37Pb 60Sn/40Pb. Wave five: use the same with soldering high-melting-point lead-free paste, like Sn/Ag3.5;Sn/Cu.75 Sn/Ag4.0/Cu.5 Sn95.5/Ag3.8/Cu0.7 Wave six: use the same with unsoldering high-melting-point lead-free paste, like Sn/Ag3.5;Sn/Cu.75 Sn/Ag4.0/Cu.5 Sn95.5/Ag3.8/Cu0.7 Wave seven: use the same with soldering lead-free solder in melting point, like Sn/Ag2.5/Cu.8/Sb.5;Sn/Bi3.0/Ag3.0 Wave eight: use the same with unsoldering lead-free solder in melting point, like Sn/Ag2.5/Cu.8/Sb.5;Sn/Bi3.0/Ag3.0 Payment terms: 1. We accept Paypal only. 2. Payments must be finished within 5 working days after bid, otherwise, Unpaid Item dispute will be reported to eBay. Shipping terms: 1. We ship via EMS/DHL/UPS to the following countries: ?USA, Canada; ?Belgium, Netherlands, Luxembourg, Italy, Germany, France, United Kingdom, San Marino; ?Austria ,Denmark ,Finland ,Greece ,Ireland ,GUERNSEY ,JERSEY ,Norway , Portugal , spain , Sweden , Switzerland; ?Bulgaria,Cyprus,Estonia,Latvia,Lithuania,Malta,slovakia,slovenia; ?Czech Republic, Hungary, Poland, Romania,. ?Australia ,New Zealand ,Korea South, Malaysia, Thailand, Philippines ,Singapore , Bruniei ,Taiwan , Macau, Indonesia, If your country doesn’t belong to the countries we listed, please contact us for detailed freight before you biding. 2. we only ship the item to the papal address. So pls be sure you fill the shipping address the same as paypal address. PLS note: be sure leave us your cell phone number , so that the item can reach you quickly and smoothly. 3. Normally, It will take 7-10 working days to reach USA, Australia, Europe, other countries may a little longer. 4. We will declare the item as gift or sample with low value. However, Import duties, taxes and Charges are not included in the item price. The buyer is responsible for all the duty and local tax. Return Policy: 1. Upon receiving the item within 7 days, any defective item not due to misused will entitled to 1 to 1 exchange. please return it to us in the original condition and package. 2. If you need any assistance on your item problem please do not hesitate to contact us, our technical support will be there to assist you. Feedback We will very appreciate you give us positive feedback (5 star) ASAP. If the item you got in any problem, PLS don’t hesitates to contact us. We will do our best to help solve the problem.One negative feedback is kill us. So please before leaving feedback, if there is any problem, contact us to try to solve it! Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
