New Bluetooth Module Slave Wireless Serial Board Module With Pcb For Arduino

US $9.00

hong kong, Hong Kong
Jan 29th

Open on mobile:
QR code

New Bluetooth Module Slave Wireless Serial Board Module with PCB for Arduino Description: 1) Wireless serial bluetooth port. 2) With free power adapter bottom board come with well power regulator. User can connect 3.3 to 5VDC and connect TX and RX to your control IO (general 3.3 to 5V digital input output of MCU or arduino IO is ok, or general TLL IO) 3) Easy to connect this module with PC, just search and key "1234" passcode. 4) With white SMD LED on the adapter board, can see the Bluetooth connection status. Step to connect: 1) Connect the wiring, power up, while the device is not connected, the bluetooth module board has a white LED flashing 2) At PC side, search bluetooth device. 3) Found name called "LINVOR" device 4) Connect it, and passcode is "1234" 5) While connection is ok, you can see the LED become always on. 6) Enjoy Basically, user can only use 2 to 5 pin in most of the application Industrial serial port bluetooth, Drop-in replacement for wired serial connections, transparent usage. You can use it simply for a serial port replacement to establish connection between MCU and GPS, PC to your embedded project and etc. Computer and peripheral devices GPS receiver Industrial control MCU projects Default serail port setting : 9600, N, 8, 1 Pairing code : 1234 Running in slave role: Pair with BT dongle and master module Usage: Coupled Mode: Two modules will establish communication automatically when powered. PC hosted mode: Pair the module with bluetooth dongle directly as virtual serial. Bluetooth protocal : Bluetooth Specification v2.0+EDR Frequency : 2.4GHz ISM band Modulation : GFSK(Gaussian Frequency Shift Keying) Emission power : <=4dBm, Class 2 Sensitivity : <=-84dBm at 0.1% BER Speed : Asynchronous: 2.1Mbps(Max) / 160 kbps, Synchronous: 1Mbps/1Mbps Security : Authentication and encryption Profiles : Bluetooth serial port CSR chip : Bluetooth v2.0 Wave band : 2.4GHz-2.8GHz, ISM Band Protocol : Bluetooth V2.0 Power Class : (+6dbm) Reception sensitivity: -85dBm Voltage : 3.3 (2.7V-4.2V) Current : Paring - 35mA, Connected - 8mA Temperature : -40~ +105 Degrees Celsius User defined Baud rate : 4800, 9600, 19200, 38400, 57600, 115200, 230400,460800,921600 ,1382400. Dimension : 26.9mm*13mm*2.2mm Pin definition : PIO8 connects with LED cathodea with 470ohm series resistor in between. LED NEGATIVE connects to ground. It is used to indicate the module state. After powered on, flashing intervals differ in different states. PIO9 is used to control LED indicating paring. It will be steady on when paring is successful. PIO11, module state switching pin. HIGH -> response to AT command; LOW or floating -> regular work status. With build-in reset circuit, reset is completed automatically after powered on. Steps to set to MASTER: Set PIO11 HIGH with a 10K resistor in between. Power on, module comes into AT Command Response Status Open HyperTerminal or other serial tool, set the baud rate 38400, 8 data bits, 1 stop bit, no parity bit, no Flow Control Via serial port, send characters "AT + ROLE = 1 r n",if successful, return "OK r n", where r n is carriage return. Set PIO11 LOW, re-power, then in Master state, automatically search for slave module and connect. Package content: Arduino Bluetooth Module x1 4P cable x1 Hello friend We will deliver the item you buy without tracking number,except the USA and Russia. if you need tracking number,please connect us and you also need pay another USD3.00.Waiting for your news. For we only provide tracking number for item which price is over USD40.00. By the way,if we can not clearly get your reply before we arrange the delivery, we will send it without tracking number. Hope you can understand. Regards Feedback 1.We maintain high standards of excellence and strive for 100% customer satisfaction! Positive Feedback is very important to us. We request that you contact us immediately BEFORE you give us neutral or negative feedback, so that we can satisfactorily address your concerns. 2. Our system automatically returns feedback once it is left for us. Contact 1.Please contact us with any comments, questions or suggestions that you may have, we will be happy to assist you. 2.You can contact us by leaving us an eBay message, or email us. You can find our email address in you Winning Buyer Notification email. 3.Our working schedule: (including hotline and online inquiry) 4. 9:00 a.m. to 6:00 p.m. (GMT +8) of Monday to Friday 9:00 a.m. to 1:00 p.m. (GMT +8) of Saturday 5.We Respond emails within 24 hours, Weekend within 36 hours . We apologize for the late reply during the holidays in Hong Kong Shipping Country Approx. Delivery time United States / United Kingdom / Australia 10-20 working days Canada 18-40 working days Chile/ Brazil / South America 35-55 working days France / Spain / Italy / Germany /Russia may take up to 6-8 weeks due to strict Custom Inspection 1.We Ship to Worldwide, except Italy, Nigeria, Brazil. due to the long delivery time . 2.Before buying, Please make sure your paypal and ebay address is correct. Or not, please correct it before payment 3.Ship to worldwide from Hong Kong within 12-24 hours after payment completed received, arrive at most destinations as above All orders will be shipped via the International Airmail service unless specially agreed by seller! Payment 1.we only accept payment view paypal , We apologize that we cannot accept other payment methods, such as cheque or postal orders . 2.All major credit cards are accepted through our secure payment processor PayPal 3.Payment must be received within 7 business days of auction closing.
