New Brooks Automation Sentry 1510 Manual Pressure Control System Pn: 12908

US $5400

Phoenix, Arizona, United States
Jun 9th

Open on mobile:
QR code

Brooks Automation / Progressive Technologies SENTRY 1510 Manual Process Pressure Control System Comes with what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from Brooks Automation and may vary slightly due to upgrades, options, or revisions this unit may or may not have. This unit is a manual unit and I do not believe is used with the Supervisor (TIM) controller. Some specifications may include features this unit does not have because it is a manual unit. There is no Supervisor in this auction (that is the controller). The Main Unit's Serial Number Tag Reads: Product: Sentry 1510 Type: Manual Style: Horizontal Mount Part Number: 11911G01 Rev. F Serial Number: 14666 Operating Range: Pressure (Negative): -3 to -23 mm H2O Flow: 2 to 50 SLM Link to the Datasheet: Brooks Automation SENTRY 1510 Presure Control System Datasheet General Description: The SENTRY 1510 controls pressure in atmospheric diffusion furnaces and other atmospheric process chambers improving process repeatability and reducing contamination. Through its rapid response to fluctuations, the production-proven SENTRY 1510 prevents backstreaming of contamination from house exhaust and provides a stable process environment even with widely fluctuating house exhaust or gas flows. The sealed system contains HCl fumes, improving worker safety. Features: Sealed system Air-flow regulation with millisecond response time Automatic set point control Analog or digital host communication Production-proven Benefits: For Diffusion/Oxidation: Enables thinner oxide control Controls contamination protection from backstreaming Improves process repeatability Saves energy Primary Applications: Diffusion Oxidation Specifications: Negative Pressure Configuration: -0.12" to -1.85" of water column. (-3 mm to -47 mm to water column.) Positive Pressure Configuration: +0.12" to +1.85" of water column. (+3 mm to +47 mm of water column.) Flow Range: 0.01 to 1.05 SCFM (0.3 to 30 LPM) Accuracy to Set Point: ±0.04" of water column. (±1.0 mm of water column.) for dry process, ±0.08" of water column. (±2.0 mm of water column.) for pyrogenic processes Response Time: 50 milliseconds to exhaust fluctuations of 100%. Response to pyrogenic ignition or extinguish will vary by installation. Materials: Ryton and Teflon with Viton elastomers Set Point Control: 0-5 volt analog, RS422/RS485 at 9600 baud, Stand alone operator keypad (I do not believe it has this option) Power Requirements: TIM (Supervisor): +15 to +24 VDC, 650 mA and -15 to -24 VDC, 50 mA (I don't believe it has this option) Power Supply: 90 - 260 VAC, 47-63 Hz, 12 W nominal Facilities Requirements: Minimum House Exhaust: Negative pressure configuration 0.4" w.c. (10 mm w.c.) more negative than set point, Positive pressure configuration -0.5" w.c. (-13 mm w.c.) Maximum House Exhaust: 5.0" of water column (125 mm of water column.) Nitrogen: Input Tube OD: .25" Minimum Pressure: 40 psig (2.8 Kg/cm2) Maximum Pressure: 100 psig (7.0 Kg/cm2) Minimum Grade: House grade or better Input and Output Connections: 1" female NPT Dimensions: 6.0" L x 3.0" W x 8.5" H (152 mm x 76 mm x 216 mm) Weight: 7 lbs. (3.2 kg) For More Pictures Please Click the Following: Picture 2 - Side View #1 Picture 3 - Side View #2 Picture 4 - Side View #3 Picture 5 - Side View #4 Picture 6 - Inside, Top Panel Removed #1 Picture 7 - Inside, Top Panel Removed #2 Picture 8 - Part Number Tag Picture 9 - Serial Number Tag For Domestic Customers: Packaging, handling, and order processing included in shipping in all domestic shipments as quoted by the shipping calculator. For International Customers there is a $25.00 minimum for packaging, handling, and order processing. International shipping to be determined by destination. Prior to shipment I need to know the following information: (1) Are you the end-user of this item? (2) If you are not the ultimate end-user of the item, please state the ultimate end user's name. (3) What is the ultimate country destination? If you have any questions please call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 10/21/10 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
