i000000 New Capacitor Capacitance Cap ESR Meter Tester Combo DMM MESR-100 + JY6013 Description : New Capacitor Capacitance Cap ESR Meter Tester Combo DMM MESR-100 + JY6013 Trust us, Believe us, for trading us: New Package + Best Quality + Tested Before Shipping! a)Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. b)Please check with your country’s customs office to determine what these additional costs will be prior to bidding/buying. Get JY6013 for Four Reasons: 1. JINGYAN M6013 V2 Auto-ranging capacitance meter. 2. M6013 have fast reading speed and high accuracy up to 1%. 3. Using 128X64 dot matrix LCD, can display 5 digit reading, Large range of measuring 0.01pF to 470mF (470000uF) capacitance, which enough for DIY user to professional engineer usage. 4. Reading a 2200uF only take ~0.2s *PLEASE DISCHARGE THE CAPACITOR BEFORE TESTING Compare M6013 old V1 and new V2 Improvement: 1) Larger measuring range, V2 can read up to 470mF 2) New large dot matrix LCD 3) New housing with stand 4) More stable on reading, (with auto running averaging function, can read pF more stable and accuracy) 5) Can use 2X AA battery rather than 9V 6) Can use mirco usb as external power. JY6013 Specification: Range Accuracy (After Zero, tested with 1nF, 1uF, 1000uF) Refresh Time (Manual Mode) *Auto mode take 0 to 2s more time depend on value Larger capacitance take more measuring time 0.01pF to 47.000nF 1%+2Digit ~0.2s to 1s 47.00nF to 47.000uF 1%+1Digit ~0.2s to 2s 47.00uF to 470.00mF 1 to 3%+1Digit (Larger capacitance will have larger error) ~0.2s to 30s Accuracy maybe affected by the test lead’s length and distance of test leads. Especially testing pF small capacitance, shortest test lead is recommended, and be careful the surrounding EMI or RF noise may affect the pF reading. 1) Accuracy: Up to 1% (detail on above table) 2) High Resolution: 5 digit 3) Measuring voltage: <0.8V 4) Clamping voltage: ~1.25V (open voltage) 5) Battery 2X AA 1.5V battery 6) External Power: 5V micro USB 7) Operating current 0.02A 8) Battery Life time: >80 Hours Operating Introduction: 1) POWER ON Press and hold the ON/ OFF circle orange button for 1 to 2 second to power on. Press and release the ON/ OFF button to shut down meter. 2) AUTO/ MANUAL mode: i) Auto Range: Press and release the RANGE button and at the first line of LCD will show “AUTO:" At auto mode meter will automatically select the best range to detect. ii) Manual Range: Scroll the manual range from 47nF, 47uF and 470mF range by press and release the RANGE button In LCD will show MANUAL at first LCD line and show at second line: 0-47NF, 47NF TO 47UF and 47UF TO 470MF. 3) 1 Key Zero: OPEN circuit the test leads’ terminal. Press and release the “ZERO" button, LCD shows “ZERO" and wait the zero disappear. If you are using the meter array socket, you need to OPEN circuit to set zero too. 4) Socket: You can use the 8 pin socket to measure the capacitor 5) Running Average: It will automatically start running average if the capacitance reading become stable and user can get more accuracy reading. During running average it will show “AVG” at right bottom LCD or it will show raw data icon “RAW” As a result, if you want to get higher accuracy reading, you can take the reading during AVG display. This function will automatically on, once the raw data is noise. 6) Backlight: LCD backlight will on during power on 7) Auto Sleep: Around 8 to 10 hours for not testing, it will shut down automatically to save power. 8) OVERFLOW or OL: Display overflow when the value is out of range, you can check that you are zero correctly. 9) PLASTIC STAND: If you don’t use the stand, press and push the lock position: Package including: 1unit x M6013 1pair x test probe Get MESR-100 for Four Reasons: 1. JINGYAN MESR-100 V2 Auto-ranging capacitor ESR and Low Ohm Meter 2. Measuring range from 0.001 to 100.0R, support IN CIRCUIT Testing. 3. Using true 100 KHz sine wave to measure the ESR value, which is equal to the testing method of capacitor manufacturer. 4. In the market, there is some technique using short pulse method to testing, but the value will be varying vs the capacitance and sometimes reading is different from the manufacturer's value. What is ESR of capacitor? 1)There is a series resistor inside capacitor, using 100kHz to remove the impedance 1/(2*pi*F*C), the impedance become small, and we can then measure the true series resistor value. 2)A bad E-capacitor will have larger ESR and create large ripple rather than filtering noise. Normally, a big capacitor is larger than 3 ohm. 3)Using this theory, we can measure the capacitor is bad/ damaged or good in condition. 4)Because our ESR meter only applies less than 15mV DC or peak to peak on a good capacitor, as a result we can use it as in circuit test. Because this low testing voltage, it cannot turn on the semiconductor inside a circuit under testing. 5)During repairing TV, LCD, Audio board, etc. we can in circuit testing the capacitor is good or not. 6)Dual terminal, for fast and easy inspect general capacitor or resistor, a printed ESR table for fast check Compare MESR100 old V1 and new V2 Improvement: 1. Change square wave to sine wave 100 KHz, reduce square wave’s high frequency component, and affect the reading passing the test leads and capacitor. 2. Higher Resolution up to 0.001 ohm. 3. Support external USB power, using standard micro-USB port. 4. 128X64 dot matrix LCD, with more larger value display and information 5. New plastic case, curve design for hand carrying. New stand for 60 degree stand on desk. 6. Use 2X AA battery, more convenience and longer battery life than 9V battery. 7. Embedded 25V capacitor table at LCD, auto display the capacitor is good or bad reference to common 25V electrolytic capacitor. Specification: Range Accuracy (After Zero, tested with 1,10,100R resistor) Refresh Time (Manual Mode) *Auto mode take 0 to 2s more time depend on value 0.000 to 1.000R 1%+2Digit ~0.4s 1.000 to 10.00R 1%+1Digit ~0.4s 10.00 to 100.0R 2%+1Digit ~0.4s Accuracy maybe affected by the test lead’s length and contact point resistance. Standard test leads is 15cm, for longer test leads need special shielding to affect the EMI inference (Can contact sales’ person for more detail) 1) Accuracy: Up to 1% (detail on above table) Wide Measurement Range: >1uF (for 0.1uF the error will be larger on equation 1/(2*pi*F*C) @ 100Khz ) 2) High Resolution: 4 digit, or 0.001Ohm @ 1 Ohm range 3) Measuring voltage: <~40mV RMS (TESTING VOLTAGE) 4) Clamping voltage: ~0.15V (open voltage) 5) Battery 2X AA 1.5V battery 6) External Power: 5V micro USB 7) Operating current 0.02A 8) Battery Life time: >80 Hours Operating Introduction: 1) POWER ON Press and hold the ON/ OFF circle orange button for 2 to 3 second to power on. Press and release the ON/ OFF button to shut down meter. 2) AUTO/ MANUAL mode: i) Auto Range: Press and release the RANGE button and at the first line of LCD will show “AUTO:" At auto mode meter will automatically select the best range to detect. ii) Manual Range: Scroll the manual range from 1R, 10R and 100R range by press and release the RANGE button In LCD will show MANUAL at first LCD line and show at second line: 0-1R, 1-10R and 10-100R. 3) 1 Key Zero: Short circuit the test leads’ terminal, cancelling the wire resistance. Press and release the “ZERO" button, LCD shows “ZERO" and wait the zero disappear. If you are using the meter array socket, you need to use a short pin to short circuit to set zero. 4) Backlight: LCD backlight will on during power on 5) Auto Sleep: Around 10 hours for not testing, it will shut down automatically to save power. 6) OVERFLOW or OL: Display overflow when the value is out of range, you can check that you are zero correctly. 7) ESR TABLE: It is for reference only, different manufacturer of capacitor has different ESR, better to test a good cap ESR and compare with what you are testing, usually bad cap with higher ESR few times larger than good one. 8) SOFTWARE ESR: Put the 25V Electrolytic capacitor value to LCD, and compare, GOOD if C < XXuF, means the capacitor maybe good condition if it is less than XXuF 9) PLASTIC STAND: If you don’t use the stand, press and push the lock position: Package including: 1unit x MESR-100 V2 1pair x 15cm test clips (as photo) The following is the delivery time, you could have a check. If you are buy from USA, we will ship by e-packet. It will reach to you in 7-12 working days. If the item send by DHL, it will reach to you in 3-7 working days. If the item send by EMS, it will reach to you in 5-10 working days. If the item send by singapore mail, and it will reach to you in 15-20 working days. If after 35 days, you still no receive the item, then please contact with us again, we will give other solutions for you(give you a full refund or sending another one to you). Hope you could be understanding us and have a nice trading expenrience with us. 1.Thank you for your great purchasing. Wish you could visit again. If you are satisfied with our items and service, your positive feedback with five stars rating will be very appreciated, for positive feedback with five star rating are what we are striving for. When you rate the shipping time part please take international transit into consideration. We will appreciate your understanding for the uncontrollable shipping time. We also give you a positive feedback, for you are the best buyer that we want to do business with you. 2. If you are not satisfied with your shopping experience, please contact us before you decide to leave a neutral or negative feedback. Since Neutral or Negative feedback won't resolve any questions for you. We will do our best to solve the problem for you as soon as possible. 3. Please rate: This is what we are striving for and we will give you the best service and meet your need. If you have any questions, please contact with us freely, you could email us at eBay message. We will answer the emails in the queue they are received. If you don't receive a reply within 24 hours (exclusive of weekends and holidays), means we did not get your email. Please ask again, thanks a lot. During the working time, we will reply you as soon as possible. If it is not weekday, please kindly be patient and considerable to give us a little more time, not just leave the neutral or negative feedback without communication, thank you for your cooperation! If you have any item problem, please feel free to contact with us, we will give you the free techincal support. Hope we can give you BEST BUYING EXPERIENCE on eBay. Welcome to visit my store likebuyshop2010 to find more items ! Shipping : 1.The item would be shipped out within 1 working days after we received the payment.E-Check will be held until cleared. 2.Our QC will test goods carefully before sent out. 3.The package will be sent by airmail.Normally delivery time is within 15-20 working days 4.We will send item to your Confirmed Shipping Address in Paypal. If you would like to post to other address , please timely leave us a note when making payment through Paypal. 5.We hope it arrive on time but since this is an international delivery, shipping time will be highly depended on the courier company and local customs/duties. If you don't receive the item after the 25 days, please contact us freely, we'll try our best to solve the delivery problem. Payment : We only accept payment through Paypal. Please make payment within 3 days after bidding, Please do not bid if you are not intending to pay for the auctions. Unpaid dispute will be filed to ebay for the non-pay bidders and unpaid transcation would be closed. please be a serious bidder. click to Enlarge click to Enlarge click to Enlarge click to Enlarge click to Enlarge click to Enlarge click to Enlarge inkfrog terapeak inkFrog Analytics
