New Cool Bms Protection Pcb Board For 4 Packs 18650 Li-ion Lithium Battery Cell

US $3.16

Hongkong, Hong Kong
Jun 9th

Open on mobile:
QR code

Home Payment Delivery details Terms of sales About us Contact us Store search Store category You may also like New Cool BMS Protection PCB Board for 4 packs 18650 Li-ion lithium Battery Cell Product Description Features: Note: If the correct welding, testing the output of non-output, use other ways to activate charging about protection board! Overview: Main IC uses the original "Ricoh" imported components. Overcharge, over discharge, over current, short circuit protection, for a variety of capacities in various shapes 3.7V lithium batteries. Japan Seiko protection IC, VISHAY, AOS, IR and other high-quality MOSFET, FR-4 plate low temperature coefficient, design, fine workmanship, testing and comprehensive. Compact, suitable for many of the requirements of highly integrated, low-cost applications to meet a wide range of performance requirements to ensure the absolute safety and reliability of the battery pack. The protection board device description: Components for Japan's Seiko S-8254AAG protection chip; Genuine Bandai America's AO4407 * 2pcs; protect the chip as well as Ricoh R5431 series. Lithium battery protection board attributes: Model: HH-P3-10.8 Dimensions: 48 * 15 * 1.0mm Charging voltage range: 4.25-4.35v±0.05v Over-discharge voltage range: 2.5-3.0v ± 0.05v Working temperature: -40 --- +50℃ Storage conditions: -40-- +80℃ Maximum operating current: 4-5A The maximum instantaneous current: 6-7A Quiescent Current: less than 6uA Resistance: less than 45mΩ Effective life: more than 50,000 hours Short circuit protection: protect, need to be recharged recovery Suitable for: 4packs 18650 lithium battery 14.8V 16.8V Main functions and features: over charge protection, over-discharge protection, short circuit protection, overcurrent protection. The protective plate using Japan's Ricoh rechargeable lithium iron phosphate battery protection IC; 1) high-accuracy voltage detection circuit; 2) terminal of the charger using high voltage devices; 3) Built-in three-stage overcurrent detection circuit (overcurrent 1, overcurrent 2, load short circuit); 4) MOS transistor can be controlled by a battery charge and discharge; 5) low standby current consumption. Function and Notice: 1, the lithium battery with protection board according to the wiring diagram connection, when the battery voltage is overcharge and over-discharge voltage between the voltage, and P +, P- charging 1 second, P + and P- output voltage of the battery voltage. 2, the battery charge function: between P + and P- plus charger to charge the battery, the battery voltage charge to overcharge detection voltage (4.25 ±0.025V), the protection circuit to cut off the charging path, to achieve overcharge protection. 3, Battery over-discharge protection: in between the P + and P- connected load to the battery discharge when the battery voltage drops to over-discharge voltage (2.7±0.05V), the protection circuit, shut off the discharge path to achieve the over-discharge protection. 4, Short circuit protection: When the P + and P- short circuit protection circuit will act quickly in 5-50uS, cut off access, short-circuit protection. 5, Overcurrent protection function: When the V- terminal voltage of (0.15 ± 0.02V), the protection circuit will act quickly in 6.7-13.9ms, cut off access, overcurrent protection. Package Contents 1 x 18650 PCB BMS Protection Board Payment Delivery details Terms of sales About us Contact us Payment 1 Thank you for you interest in our item. As Paypal is our only payment option, please make your payment properly and timely through that. 2 Please kindly notice that a non-payment dispute will be opened automatically if full payment is not received after 4 days of auction. Delivery details 1. As we have chosen not to ship to some countries and areas, please check shipping exclusion list before you bid or buy. 2. Orders will be processed and shippied within 24 hours after your full payment is confirmed by us. You will get the noticification immediately once we post your order. 3. To ensure safety, we will ship to Paypal Confirmed addresses only (your credit card billing address must match the shipping address you provide during checkout.) If you would like your item to be shipped to an address other than your billing address, please contact us through Ebay, Any non-received items causd by invalid address registered on Paypal are not in our refund or replacement policy. Notice: We are not responsible for customs, duties or taxes associated with any order, nor will be mark your order as a gift. Terms of sales About us Our listing price includes the value of goods, packaging cost, and export taxes,It does not include international import duties. All disputes arising from the import duties will be submitted to ebay for solution. Thank you for your understanding! Contact us We value your feedback and suggestions! If you are happy with your purchase and our service, please give us postive feedback and leave “5 STARS” in your rating. Please contact us about any problems before leaving us neutral or negative feedback. We hope we can get a chance to fix the problem. On Sep-22-15 at 04:04:02 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
Country/Region of Manufacture	China
MPN	Does not apply
UPC	Does not apply
