New Edu Classroom Special .. Learn +5v Power Supply Design Kit .....qty 10 Kits

US $29.96

Bolingbrook, Illinois, United States
Jan 29th

Open on mobile:
QR code

LEARN POWER SUPPLY DESIGN QTY 10 Kit # 400039 Requires Soldering Plugin Breadboard Power Supply +5V Kit with FREE Parts Kit GREAT Revised PRODUCT....GREAT New Low PRICE Above shows +5V and +12V inserted into Solderless Breadboard with Wall Wart ( BREADBOARD IS NOT INCLUDED ) GREAT Revised PRODUCT....GREAT New Low PRICE QTY 1 Kit # 400039 Requires Soldering This Power Supply Kit has superior regulation because of the quality components. +5V TO-220 7805 Type Regulator with Low Dropout Voltage Features: 1. Multiple Power Supplies can be used with multiple breadboards. It creates an excellent prototyping environment allowing your heavy duty lab Power Supply to be used on the bigger loads. 2. Low Cost 3. Very small and compact 4. Uses the 78XX series regulator. The most common regulator out there. 5. Multiple Voltages available 5-6-8-9-12-15-18-24 vdc. 6. A fuse can be added to create an independently fused Power Supply for custom applications. 7. A blocking diode has been added to protect the input from reverse polarity at hookup. 8. LED designate Output Voltage ON. 9. Allows you to utilize some of those wall wart Power Supplies that you have laying around. There is always an overabundance of these. Give them a new life by recycling them into your new test fixturing. 10. Provide an in depth understanding of Power Supply design. 11. Easy to assemble and solder. 12. Easy connect/disconnect to a wall wart with a 2.1mm coaxial socket. 13. Easy connect/disconnect to a breadboard. It plugs into the breadboard power distribution strips. 14. Short circuit protection 15. Easy to follow, step by step assembly instructions. 16. Detailed linear Power Supply operations tutorial. 17. Detailed schematic 18. Detailed part list 19. Detailed MC78XX spec sheet Includes: Qty 1 +5V Power Supply Plugin Kit #400039 FREE Parts Kit #400124 includes #100309 Qty 2 10K Resistor SIP 8 Pin 4 Resistors #100734 Qty 2 CAP 47 uF RADIAL 35V #100673 Qty 2 CONN PCB 1x5 .1 SP Header Vertical Male #100725 Qty 4 PCB Pushbutton Vertical Tactle Switch #100528 Qty 4 Yellow 3mm thru Hole STANLEY LED's #AY3361X For a PDF Schematic of the Power Supply - click here www.DAQstuff.com/ebaydata/400049-400124.pdf ( BREADBOARD IS NOT INCLUDED ) For a PDF and 'LEARN POWER SUPPLY DESIGN' guide - click here www.DAQstuff.com/ebaydata/400039/400039-rev3-PDF.pdf Requires Soldering Solders in minutes ! Breadboard sold seperately ( NOT included ) GREAT Revised PRODUCT....GREAT New Low PRICE Check out the Breadboard Section in our store - DAQ stuff store 400039 After purchasing, pay instantly with your credit card through PayPal!
