New Festo Cp-fb11e Pnuematic Field Bus Node Cp Valve, Nnb

US $229.99

Rockingham, North Carolina, United States
Jan 29th

Open on mobile:
QR code

NEW FESTO CP-FB11E PNUEMATIC FIELD BUS NODE CP VALVE, NNB Click to View Image Album NEW FESTO CP-FB11E PNUEMATIC FIELD BUS NODE CP VALVE, New No Box The CP installation system integrates valve manifolds CPV and CPA, and various I/O modules into a single installation concept. All CP valve terminals and CP modules are connected using a ready to install CP cable and are attached to the CP fieldbus node. One CP valve manifold and one CP input module make up an installation string that ends at the CP fieldbus node. High-speed machines require short pneumatic tubing and the valves must be mounted close to the cylinders. The CP installation system was developed in order to avoid individual wiring for each valve and to assure short pneumatic connections. The installation system supports a maximum of 4 installation strings which can be connected to the fieldbus node. Each string can be extended up to a maximum length of 10 metres. The CP fieldbus node is the central connection point for the fieldbus and for the valve actuation and sensor power supply. Relevant bus parameters are set by means of switches and the fieldbus connector is attached to the node. The power supply for the sensors connected to the input modules is separate from the load voltage of the valves. The CP string is used to exchange the input and output states of interconnected modules with the CP fieldbus node, and supplies power separately to the valves and input module. Components included with the CP installation system: Fieldbus node Control block Output module - Pneumatic (valve manifold) - CP-A08-M12-5POl: 8 electrical outputs, 5-pin, PNP (8xM12) - CP-A08N-M12: 8 electrical outputs, 4-pin, NPN (8xM12) Input module - CP-E16-M12x2-5POL: 16 inputs, 5-pin, PNP (8xM12) - CP-E16N-M8: 16 inputs, 4-pin, NPN (8xM12) - CP-E16-M8: 16 inputs, 3-pin, PNP (16xM8) - CP-E16N-M12x2: 16 inputs, 3-pin, NPN (16xM8) - CP-E16-M8-Z: 16 inputs, 3-pin, PNP/NPN (16xM8), with separate power supply for sensor - CP-E16-KL-IP20-Z: 16 inputs, terminals, IP 20, with separate power supply for sensor Sensors, limit switches and small-load electrical power consumers (signal lamps, solenoid valves etc.) are connected to I/O modules. The CP valve manifolds and CP input modules do not need any other electrical connection apart from the CP cable, nor do they require any module-specific settings. This minimizes the installation space required for the electrical connections to the modules and valves. Fieldbus protocols - FB5: Festo, ABB CS31, Moeller SUCONET K - FB6: INTERBUS - FB8: Allen Bradley (1771 R10) - FB11: DeviceNet Economy 1 M12 round socket - FB13: PROFIBUS DP (12 MBd) Control blocksControl blocks - SF3: Festo control block with fieldbus connection - SB6: Allen Bradley control block, SLC embedded - SF6: Allen Bradley control block with Device Net Features - Decentralized mounting of valves - Central electrical installation - Only one connection point for the fieldbus - Only one connection for the power supply - Reduced space requirement for electrical connections Accessories - Connector cable KVI-CP-1-... - Connector cable for chain link trunking KVI-CP-2-... - Power supply socket Straight socket NTSD-GD-... Angled socket NTSD-WD-... - Connection socket Straight socket FBSD-GD-... Angled socket FBSD-WD-... - Fieldbus connector for Profibus DP FBS-SUB-9-GS-9 - Straight sensor plug SEA-... - Connection set SEA-KL-SAC10/30 for CP-E16-KL-IP20-Z - Top-hat rail mounting for modules CP-TG-HS35 Fieldbus variants: Of the more than 20 different fieldbus systems (protocols) available from the market, several have emerged as the most important variants. Festo supports these by means of various fieldbus nodes (FBxx) on the valve manifolds. Festo fieldbus: A fieldbus developed by Festo with simple prompting, supported by control systems included in the FPC, SF and IPC series (Festo FB5). Interbus: An open fieldbus standard, originally developed by Phoenix Contact and now in worldwide use. Important installation accessories such as bus plugs must be obtained from Phoenix or its partners (Festo FB6). Allen Bradley: The fieldbus node supports the 1771 Remote I/O fieldbus from Allen Bradley / Rockwell Automation. DeviceNet: An open fieldbus system based on CAN technology originally developed for the automotive sector. DeviceNet was originally marketed by Rockwell (Allen-Bradley). There are other CAN derivatives as well (Festo FB11). Profibus DP: An open fieldbus standard originally developed by Siemens and now in worldwide use (Festo FB13). Integrated Festo PLC (SF3): A high performance miniature control system from Festo was integrated into the SF3 valve terminal node. This allows for autonomous control of up to 34 inputs and 34 outputs on-site with IP 65 protection – no need for a control cabinet. With the Festo fieldbus, additional I/Os and expanded functions can be installed and controlled, thus creating a programmable valve manifold group. The SF3 control block can be operated as required as a stand-alone, a fieldbus master or a fieldbus slave. 31 slaves with up to 1048 inputs and outputs can be controlled via the fieldbus in the master operating mode. The SF3 node can be used as an intelligent slave within the fieldbus in the slave operating mode. This enables autonomous on-site pre-processing or partial start-up. The SF3 valve terminal can be programmed with FST 200 or a display and control device can be directly connected on-site via an RS 232 programming interface. Integrated Allen Bradley PLC (SB60): The SB60 control block is a high performance Allen Bradley miniature controller (SLC500) enclosed in a sturdy aluminium housing with IP 65 protection. The SLC5/02 processor technology licensed by Rockwell Automation provides computing power which is tailored to the requirements of a fully expanded valve terminal. The controller is programmed using Allen Bradley’s standard RSLogix500 programming software. Integrated Allen Bradley PLC with DeviceNet (SF60): The SB60 control block is an Allen Bradley SLC500 controller with an additional DeviceNet link enclosed in a sturdy aluminium housing with IP 65 protection. In addition to the SLC5/02 processor, the SF60 control block is also equipped with an integrated type 1747-SDN DeviceNet scanner. SLC5/02 processor technology and the 1747-SDN scanner technology licensed by Rockwell Automation provide computing and networking power, which is tailored to the requirements of a fully expanded valve terminal with networked system synchronisation. The controller is programmed and configured using standard Allen Bradley software. The program is created using RSLogix500 and DeviceNet, and is configured using RSNetworx for DeviceNet. Shipping Info: Weight: 6 Lbs Dimensions: 12" X 6" X 9" Shipping Information on Large Items:You can get Instant Online Freight Quotes at: Freightquote or at Freight101 Both are quick and easy to use. Please enter the Shipping Dimensions and Shipping Weight Listed Above.We are a business with a Loading Docking Item will be Shipped From Rockingham, NC 28379 Please contact Tom at 910-995-1336 with any questions, comments, or requests.Please ask questions as EARLY as possible, before the end of the item's auction. Payment Prompt Payment Is Expected !! I accept the following forms of payment: PayPal Shipping & Handling Please See Auction Description to Determine Shipping Costs !! Thanks Again For Your Purchase !! We will e-mail you tracking information after the item ships. Please leave feedback for us on ebay after receiving your item. We will do the same for you.Sincerely,Tom910-995-1336 Enter ZIP Code and click button to see prices: UPS Ground Click to View Image Album Click to View Image Album Click to View Image Album Click to View Image Album Click to View Image Album FREE scheduling, supersized images and templates. Get Vendio Sales Manager. FREE scheduling, supersized images and templates. Get Vendio Sales Manager. Over 100,000,000 served. Get FREE counters from Vendio today! Click Here. Double your traffic. Get Vendio Gallery - Now FREE!

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	festo
Model	CP-FB11 E
