New Horiba Stec Sec-z512mgx Sih4 100 Sccm Mass Flow Controller, Asm 1011-209-01

US $837.20

Phoenix, Arizona, United States
Jan 30th

Open on mobile:
QR code

NEW Horiba STEC SEC-Z512MGX SiH4 100 sccm Mass Flow Controller, ASM PN: 1011-209-01 Comes with what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from Horiba STEC and may vary slightly due to upgrades, options, or revisions this unit may or may not have. This part is new, old stock from ASM. The package may have been opened and re-sealed to recalibrate the units so that ASM could ship them when a customer ordered them. The calibration is past due however. ASM Information: Part Number: 1011-209-01 Description: FC-STEC-Z512-100 SCCM-SIH4-AI-NO-124MM The Unit's Tag Reads: Model Number: SEC-Z512MGX Flow Rate: 300 sccm Gas: N2 Valve: O Treat: SUC Fitting: 4CRL Sig: T1 Protocol: F-NET, 485 MR-MG.: 03 Calibration Gas: N2 Calibration Factor: 1.000 Temperature: Ambient Type: 002437 Link to the Datasheet: Horiba STEC SEC-Z500 Series Mass Flow Controller Datasheet Specifications: Full-Scale Flow Rate: 300 SCCM (N2 Conversion Flow Rate) Valve Type: O: Normally Open, C: Normally Closed (This unit is Open) Flow Rate at Fully Closed Control Valve: < or = to 2% F.S. Flow Rate Control Range: 2-100% of F.S. Accuracy*2: ±1.0% S.P. (Flow rate > 25% F.S.), ±0.25% F.S. (Flow rate < or = to 25% F.S.) Operating Temperature: 5 to 50°C (recommended temperature range: 15 to 45°C) Response: < or = to 1 second: Over full flow rate range Linearity: < or = to ±0.5% F.S. Repeatability: < or = to ±0.2% F.S. Operating Differential Pressure: 50 to 300 kPa (d) Max. Operating Pressure: 450 kPa (g) Pressure Resistance: 1000 kPa (g) Leak Integrity: < or = to 5 x 10-12 Pa x m3/s (He) Flow Rate Setting Signal: 0.1 to 5 V DC (2% to F.S.); Input impedance 1 MΩ or higher Flow Rate Output Signal: 0 to 5 V DC (0% to F.S.); Minimum load resistance 2 kΩ or higher Digital Interface: With address function: RS-485 (transmission speed 38,400 bps), F-Net Protocol Wetted Materials: 316L Stainless Steel (polished surface) Power Supply: +15 V ±5%, 150 mA. -15 V ±5%, 150 mA. Signal Response: Analog: D-Sub 9-pin (TOP) Digital: 2 LAN jacks (TOP) Standard Fitting*3: 1/4 inch VCR equivalent, Option: 1.125 inch IGS, 1.5 inch IGS Mounting Position: Free Notes: 1: The gas type and full scale settings for the SEC(SEF)-Z512MGX, Z522MGX, and Z522MGXN can be changed by the operator, using special software. 2: The flow rate precision guaranteed temperatures conform to SEMI E56-1296 standards. The precision is that associated with the full-scale MR and MG number values. 3: IGS: Integrated Gas System *: SCCM and SLM are notations indicating the gas flow rate (mL/min, L/min, at 0°C and 101.3 kPa). For Domestic Customers: Packaging, handling, and order processing included in shipping in all domestic shipments as quoted by the shipping calculator. For International Customers there is a $10.00 minimum for packaging, handling, and order processing. International shipping to be determined by destination. Prior to shipment I need to know the following information: (1) Are you the end-user of this item? (2) If you are not the ultimate end-user of the item, please state the ultimate end user's name. (3) What is the ultimate country destination? If you have any questions please call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 05/23/12 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items. On Oct-31-13 at 21:08:57 PDT, seller added the following information: Click Here. Double your traffic. Get Vendio Gallery - Now FREE!

Condition	New other (see details) : A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“This part is new, old stock from ASM. The package may have been opened and re-sealed to recalibrate the units so that ASM could ship them when a customer ordered them. The calibration is past due however.”
