New Hwacheon Hl580 Lathe High Speed Precision 23" Swing

US $40,995.00

Long Beach, California, United States
Jan 30th

Open on mobile:
QR code

HWACHEON HL580 LATHE ------------------------------------------------------------------------------------------------------------------------------------------------------- NEW 23" x 60" HWACHEON MODEL HL-580 LATHE INVENTORY # 3889 MODEL: HL-580 MADE IN KOREA TO JAPANESE STANDARDS SPECIFICATIONS: MAXIMUM SWING OVER BED: 22-3/4" SWING OVER BED FROM FACE PLATE UP TO 7” IN SHORT TAPER NOSE 6” IN CAMLOCK NOSE: 23” SWING OVER CROSS SLIDE: 14-11/64" SWING OVER GAP: 31-9/10" DISTANCE FROM FLOOR TO CENTER: 43-11/16” DISTANCE FROM BED TO CENTER: 11-1/4” DISTANCE BETWEEN CENTERS: 60" SPINDLE NOSE: D1-8 SPINDLE BORE: 3 1/32" SPINDLE BORE TAPER: MT # 7 TAPER OF CENTER: MT # 5 NUMBER OF SPINDLE SPEEDS: 12 SPINDLE SPEED RANGE: 28 TO 1,350 RPM NUMBER OF CROSS AND LONGITUDINAL FEEDS: 40 RANGE OF LONGITUDINAL FEEDS: 0.0014" - 0.0196"/REV. & 0.0028 – 0.0392” / REV. RANGE OF CROSS FEEDS: 0.0015" - 0.0212"/REV. & 0.0029 - 0.0424”/REV. INCH THREADS: 80 ~ 2 TPI METRIC THREADS: 0.25 ~14 MM PITCH TAILSTOCK SPINDLE TRAVEL: 6" TAILSTOCK TAPER OF CENTER: MT # 5 WIDTH OF BED FACE: 16-1/2” WIDTH OF GAP (FROM FACE PLATE): 10-5/8” MAIN SPINDLE MOTOR: 10 HP OR OPTIONAL 15 HP COOLANT PUMP MOTOR: 100 W NET MACHINE WEIGHT: 6,440 LBS (APPROXIMATE) FLOOR SPACE: 124" x 40" (APPROXIMATE) FEATURES: NUMBER (12 STEPS) AND RANGE OF SPEEDS OF THIS LATHE IS SO CREATED THAT THE MOST SUITABLE CUTTING SPEED MAY BE GIVEN TO ANY SIZE OF WORKPIECE DIAMETER WITHIN THE POSSIBLE RANGE OF CUTTING SIZE, NAMELY, WITHIN THE RANGE OF SWING OVER BED. THE MAIN SPINDLE IS SUPPORTED AT THREE POINTS BY PRECISION BEARINGS AND ITS HOLE IS GENEROUSLY SIZED AUTOMATIC FORCED LUBRICATION SYSTEM SUPPLIES LUBRICANT TO EVERY SLIDING WAY AND DRIVING MECHANISM INSIDE THE HEADSTOCK BY LUBRICATING DEVICE INSTALLED INSIDE APRON, AUTOMATIC LUBRICATION IS PROVIDED BETWEEN CARRIAGE SLIDEWAYS AND BEDWAYS THE FEED MECHANISM PERMITS POSITIVE SHIFT FROM THE NORMAL FEEDS TO THE REVERSE, AND VICE-VERSA, BY SIMPLE OPERATION OF THE LEVER ON THE FRONT FACE OF HEADSTOCK HOUSING OR ALSO THE ONE AT THE APRON AN ADJUSTABLE CARRIAGE FEED STOP DOG IS PROVIDED ON BED AS WELL AS A POSITIVE MICROMETER STOP THE MACHINE IS EQUIPPED WITH AN OVERLOAD SAFETY DEVICE FOR FEEDING AND THREAD CUTTING TAPER-CUTTING ATTACHMENT AND REAR TOOLPOST ARE EASILY ATTACHED BY MEANS OF CARRIAGE GROOVES OF BOTH SIDES CROSS FEED SCREWS ARE ALWAYS SUPPLIED A PROPER QUANTITY OF GREASE MORE THAN ONE TIME PER WEEK MAINTAINING A SMOOTH TRAVEL UNDER MAXIMUM ACCURACY BED IS SO DESIGNED TO PREVENT TORSION, SIDE-WALL IS DOUBLE WALL AND RIB TYPE HARDENED AND GROUND BEDWAYS ARE MADE OF HIGH TENSILE CAST IRON. PRODUCED UNDER THE LICENSE OF U.K. MEEHANITE KNOW-HOW LOWER PORTIONS OF BED CASTING ARE BOX-SHAPED AND ARE FULL LENGTH, FORMING THE LEGS, CHIP PAN AND COOLANT RESERVOIR THE HYDRAULIC DISK BRAKE PROVIDES SAFE QUICK BRAKING OF THE SPINDLE WITHOUT GENERATION OF HEAT IN THE HEADSTOCK DIAMETER OF TAILSTOCK SHAFT IS 75MM AND THE OVERALL LENGTH IS HARDENED AND GROUND. BY LOOSENING CLAMP LEVER, WHICH KEEPS HIGHER SLIDING EFFICIENCIES AND BETTER WEAR RESISTANCE OF CARRIAGE. SHOP MORE LATHES HERE NEW - FOB LONG BEACH, CA CONTACTING NORMAN MACHINE TOOL, LTD: For immediate response to questions, please contact us at 1-800-394-4399 during business hours. (Weekdays, 9am - 5pm EST) If you contact us by email, or after business hours, we will answer your questions as soon as possible. NEW MACHINE NOTIFICATION TO PROSPECTIVE BUYERS: Norman Machine Tool, Inc strives to keep listings current for our customers. Manufacturer's specifications and availability are subject to change without notice. Stock photos are to be considered representations only and may show optional accessories, different models, or possible color differences from the actual machine being offered for sale. CONTACT US 1311 South Ponca Street - Baltimore, Maryland 21224. Phone 800-394-4399 - Fax 410-633-7737. RETURNS Returns will not be accepted without prior approval. If you need to make a return, please contact us before you ship the merchandise back so we can issue you a Return Merchandise Authorization (RMA) number. All items are sold with the best intentions and most complete description available. PLEASE ASK QUESTIONS BEFORE BIDDING!!! Buyer must pay for return shipping. RUN THREE PHASE MOTORS WITH SINGLE PHASE POWER Use a Phase-A-Matic Static or Rotary Phase Converter. Buy the best & buy Phase-A-Matic. Phase-A-Matic phase converters are proven to last for 20 to 30 years. You can run multiple three phase motors from just one phase converter, allowing you to run multiple three phase motors off single phase power! View Phase-A-Matic in our Phase Converter aisle of our eBay store! ............ DISCLAIMER: The information and pictures are believed to be accurate to the best of our knowledge, obtained from sources deemed reliable. However, we do not guarantee accuracy of information and cannot be responsible for any errors or omissions. An inspection should be made. The information on the web site should not be used for formal quotation. Price and information presented in the write ups on the web site are subject to change without notice. Please contact one of our sales representatives if you require more information or a current formal quotation. NORMAN MACHINE TOOL, LTD. CONDITIONS OF SALE: INSPECTION AND TEST EQUIPMENT Inspection & Test Equipment will be sold "AS IS" with a conditional return policy on a case by case basis. Please ask questions! The equipment's condition stated in the listing is accurate to the best of our knowledge. We do not specialize in these products and have no way of checking them beyond visual and some minor mechanical functions. We assume most of this equipment must be calibrated professionally. We feel the low prices we offer more than makes the equipment a great value! MDNA 30 DAY WARRANTY Every used machine offered (unless sold on an "as is" basis or brokered) bears a thirty day return privilege. In the event it is found mechanically unsatisfactory (excludes electrical*, as well as original manufacturer’s accuracies and tolerances), it may be returned within thirty (30) days of shipment, freight prepaid, provided it is in the same condition as when shipped from Norman Machine Tool, Ltd., for full refund of purchase price or repaired at the seller's sole discretion. All new machines that have been manufactured by others that have warranties, expressed or implied, are hereby expressly limited to the warranty of the original manufacturer of the goods. All implied warranties of merchantability and fitness for a particular purpose are hereby disclaimed and excluded from this agreement. Care is taken to give reliable descriptions but these are not guaranteed and prospective purchasers are advised to check vital details. We also reserve the right to correct any stenographic errors. All specifications and descriptions of said goods are approximate only. Seller makes no representation or warranty that said goods conform to any specification, description and condition or performance, it is the buyer's responsibility to inspect the goods and ascertain if the specifications, description, and condition of the goods conform to the buyer's requirements. Any warranty concerning said goods made by a third party is enforceable only against the third party and not the seller. Conforms to the mdna code of ethics. 30 Day MDNA Warranty applies to items sold at the advertised price.This warranty does not apply to Best Offers without prior agreement, or items sold As-Is. PAYMENT DETAILS: Norman Machine Tool Ltd. gladly accepts PayPal, Visa, Master Card, American Express and Discover. We can run your credit card at our warehouse, or if your prefer, even without an account, you can sign into PayPal as a guest and use your credit card. Local pickups at our warehouse in Baltimore, MD are required to pay 6% Maryland state taxes to abide by Maryland state laws. SHIPPING DETAILS All shipping originates from 21224 zip code. We ship as soon as possible after receipt of payment. Large items that must be shipped via truck will ship as soon as the truck can be secured, usually within 10 business days. Special preparation, such as crating, will delay shipment and will be available at additional cost. We can secure your equipment on a pallet, starting at $50 and varying based on the equipment size, weight, and materials needed. The buyer pays for all shipping. All items need to be paid for within 72 hours of auction end. Go Back to Our Store Homepage CONTACT US 1311 South Ponca Street - Baltimore, Maryland 21224. Phone 800-394-4399 - Fax 410-633-7737.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MANUFACTURER	HWACHEON
Model	HL580
