New Idec Electronic Timer Rte-p11 Nib 24vac/dc

US $260

Alpharetta, Georgia, United States
Jun 9th

Open on mobile:
QR code

• 20 time ranges and 10 timing functions • Time delays up to 600 hours • Space-saving package • High repeat accuracy of ± 0.2% • ON and timing OUT LED indicators • Standard 8- or 11-pin and 11-blade termination • 2 form C delayed output contacts • 10A Contact Rating Operation System Solid state CMOS Circuit Contact Configuration 2 Form C, DPDT (Delay output) Allowable Voltage / Allowable Current 240V AC, 30V DC / 10A Maximum Permissible Operating Frequency 1800 cycles per hour Rated Load Resistive 10A 240V AC, 30V DC Inductive 7A 240V AC, 30V DC Horse Power Rating 1/6 HP 120V AC, 1/3 HP 240V AC Life Electrical 500,000 op. minimum (Resistive) Mechanical 50,000,000 op. minimum Operation Type Multi-Mode Time Range 0.1sec to 600 hours Pollution Degree 2 (IE60664-1) Over voltage category III (IE60664-1) Rated Operational Voltage AF20 100-240V AC(50/60Hz) AD24 24V AC(50/60Hz)/24V DC D12 12V DC Voltage Tolerance AF20 85-264V AC(50/60Hz) AD24 20.4-26.4V AC(50/60Hz)/21.6-26.4V DC D12 10.8-13.2V DC Input off Voltage Rated Voltage x10% minimum Ambient Operating Temperature -20 to +65?C (without freezing) Ambient Storage and Transport Temperature -30 to +75?C (without freezing) Relative Humidity 35 to 85%RH (without condensation) Atmospheric Pressure 80kPa to 110kPa (Operating), 70kPa to 110kPa (Transport) Reset Time 100msec maximum Repeat Error ±0.2%, ±20msec* Voltage Error ±0.2%, ±20msec* Temperature Error ±0.5%, ±20msec* Setting Error ±10% maximum Insulation Resistance 100M? minimum (500V DC) Dielectric Strength Between power and output terminals: 2000V AC, 1 minute Between contacts of different poles: 2000V AC, 1 minute Between contacts of the same pole:1000V AC, 1 minute Vibration Resistance 10 to 55Hz amplitude 0.5mm2 hours in each of 3 axes Shock Resistance Operating extremes: 98m/sec2 (10G) Damage limits: 490m/sec2 (50G) 3 times in each of 3 axes Degree of Protection IP40 (enclosure) (IEC60529) Power Consumption (Approx.) TYPE RTE-P1, -B1 RTE-P2, -B2 *For the value of the error against a preset time, whichever the largest, applies. AF20 120V AC/60Hz 6.5VA 6.6VA 240V AC/60Hz 11.6VA 11.6VA 24V AC 60Hz/DC 3.4VA/1.7W 3.5VA/1.7W D12 1.6W 1.6W Mounting Position Free Dimensions RTE-P1, P2 40Hx 36W x 77.9D mm RTE-B1, B2 40Hx 36W x 74.9D mm Weight (Approx.) RTE-P1 RTE-P2 RTE-B1, -B2 87g 89g 85g
