New Igus Energy Chain Cable Track Carrier 3d Printer Cnc Z08.16.028 39" 50 Links

US $15.99

Salt Lake City, Utah, United States
Feb 26th

Open on mobile:
QR code

NEW igus Energy Chain Cable Track Carrier 3D Printer CNC Z08.16.028 39" 50 Links Series Z 08 - to be filled in the inner radius 1. Very easy to fill - ideal for harnessed cable assemblies 2. Small pitch for low-noise and smooth operation 3. Limited torsion tolerance 4. Lightweight 5. Patented push button principle holds the links together 6. Cable-friendly interior 7. “E” Series features split crossbar along the outer radius 8. “Z” Series features split crossbar along the inner radius 9. Integrated strain relief option Inner widths Bi: 0.39 up to 1.97 (10 - 50 mm) Bending radii R: 1.1, 1.5, 1.89 (28, 38, 48 mm) Pitch: 0.79 (20 mm) per link = 16 links/ft (50/m) When to use Series Z 08 If filling is required without opening and closing If price is an issue If quiet operation is required When not to use Series Z 08 “Z” Series is unsuitable for gliding applications Series 09 "Zipper" Installation dimensions Part No. : Z08-16-028-0 Inner width Bi [inch]: 0.39 (10 mm)0.63 (16 mm)0.79 (20 mm)1.18 (30 mm)1.57 (40 mm)1.97 (50 mm) Bending radius R [inch]: 1.1 (28 mm)1.5 (38 mm)1.89 (48 mm) Travel distance S [ft]: Fixed end dM [ft]: Chain length** [ft]: 3.2917 Number of chain links : 50 External width Ba [inch]: 0.95 (24.2 mm) H* [inch]: 2.95 (75 mm) D [inch]: 2.68 (68 mm) K [inch]: 5.12 (130 mm) Hi [inch]: 0.57 (14.6 mm) Ha [inch]: 0.76 (19.3 mm) Weight per link [oz.]: - Weight [lbs/ft]: 0.161 (0.24 kg/m) * The required installation clearance isHF = H + 0.59 (15 mm) (in the case of 0.2 lbs/ft (0.3 kg/m) additional load)If extremely restricted space is available, please consult us. ** The calculated length corresponds to the chain length without mounting brackets. -2.82.8 A=Moving End , B=Fixed End Pitch: 0.79 (20 mm) per link Links per ft: 16 (50/m) Travel: S Chain length = S/2 + K Unsupported length Dependency of the unsupported length on the additional load X axis: Unsupported length in ft FLB/FLG Y axis: Additional load in lbs/ft Lower scale: Length of travel S in ft FLB = unsupported with permissible sag FLG = unsupported with straight upper run Payment: Only PayPal payments are accepted for shipments. Local pickups can be paid with cash. Return Policy: We stand behind all our products. If there is a problem, contact us to let us know you would like to return the item for a refund. The item must be returned within 14 days. Return shipping is not covered by us. Shipping: YES, we offer combined shipping! If you have purchased multiple items, do not send payment until we send an adjusted invoice with actual combine shipping costs. Most items are shipped via USPS Priority Mail. The cost may be slightly more, but you will receive your item MUCH quicker, and more reliably. Larger items will be shipped via UPS Ground. International buyers may need to pay additional Customs or Tax fees before the item is released to the buyer. We are not responsible for such fees. The buyer is fully responsible for these fees. Powered by SixBit's eCommerce Solution

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Igus
MPN	Z08.16.028
