New In Box Tenma 72-6644 10mhz Sweep Function Generator With Frequency Counter

US $219.69

Saint Louis, Missouri, United States
Jan 29th

Open on mobile:
QR code

THIS ITEM UP FOR BUY IT NOW PRICE IS A NEW IN BOX TENMA 72-6644 10MHz Sweep Function Generator with Frequency Counter Technical Data Sheet (511.36KB) EN NEW IN ORIGINAL BOX Product Information 10MHz Sweep Function Generator with Frequency Counter Features: •Eight digit LED display •Sine, square, triangle, ramp, pulse and skewed sine output •50ohm output •TTL output •Varible: Symmetry, amplitude, DC offset, sweep width and rate •Linear and logarithmic sweep modes •VCF input •Built-in 1.6GHz frequency counter •Two input channels with attenuation (-20dB) •Measures frequency •RS-232 interface •Power requirements: 120V/240VAC, 50/60Hz Specifications Range Generator frequency 1Hz~10MHz in 7 range steps VCF voltage level 0~10VDC Output amplitude 2V~20V p-p (open), 1V~10V p-p (50?) Sweep time 20msec~2sec Sweep width >100:1 Frequency variable >=20:1 Variable offset ±10VDC Max Variable symmetry >=3:1 Frequency counter CH-A: 5Hz~100MHz CH-C:100MHz~1.6GHz Input sensitivity 70mV RMS Input impedance CH-A: 1M?, CH-C: 50? Gate time 0.1sec, 1sec, 10sec Period 0.1sec~10sec Dimensions 81/2" (W) x 31/4" (H) x 101/4" (D) Bandwidth: 10MHz External Depth: 10.25" External Height: 3.25" External Width: 8.5" Modulation Type: - Plug Type: - SVHC: To Be Advised Signal Generator Modulation: - Signal Generator Type: Function Supply Voltage Max: 120V Supply Voltage Min: 110V Sweep Rate Range: 100:1 lin/log FAST SHIPPING WITH USPS PRIORITY MAIL PLEASE CHECK OUT MY OTHER AUCTIONS INTERNATIONAL SHIPPING WILL BE HIGHER AND MUST REQUEST SHIPPING QUOTE BEFORE BIDDING OR BUYING TO GET CORRECT SHIPPING AMOUNT PAYMENT EXPECTED WITHIN 10 DAYS AS PER EBAY RULES. COMBINED SHIPPING IS AVAIABLE WITH 2 OR MORE AUCTIONS WON, PLEASE SEND MESSAGE IF COMBINING MULTIPLE ITEMS BEFORE SENDING PAYMENT TO GET DISCOUNTED RATE. PAYPAL ACCEPTED SO BID OR BUY NOW AND GOOD LUCK IF BIDDING Please check the item and shipping costs and make sure that you are happy with the terms and description BEFORE you bid. Be sure to examine the pictures closely. Please also ask any questions you may have before you bid. We try to be as upfront about condition of any item as we can without writing a book. If you are unclear about anything, we urge you to ask us! We will be happy to respond. We pack items very carefully PLEASE LET US KNOW IF ANYTHING IS NOT AS ORDERED WHEN RECEIVED SO THAT IT MAY BE CORRECTED BEFORE FEEDBACK IS LEFT SO WE ARE ABLE TO HELP YOU WITH A RETURN OR REFUND IF NECESSARY. Check out my other items! Be sure to add me to your favorites list!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	MCM TENMA
Country/Region of Manufacture	Korea, Republic of
Model	72-6644
