NEW INFRARED LASER DIODE MODULE 980nm IR with SMA fiber optic launch made in USA, US $279 – Picture 0
NEW INFRARED LASER DIODE MODULE 980nm IR with SMA fiber optic launch made in USA, US $279 – Picture 0

New Infrared Laser Diode Module 980nm Ir With Sma Fiber Optic Launch Made In Usa

US $279

  • Glendale, Arizona, United States
  • Jun 23rd
Open on mobile:
QR code
45mW, 980nm Diode Laser Module New, US made, custom laser diode module designed for a medical / dental application. It features a sophisticated drive circuit with current and temperature regulation, SMA fiber launch with low pass filter, internal cooling fan with TEC cooled laser diode, and monitor outputs for current and temp.  The laser diode is made by SLI and has an output rated at 300mW and is a 9mm can package. Click HERE for hook-up info and diode spec sheet. Note: Hook-up sheet shows an external fan.This unit was revised to have an internal cooling fan. SPECIFICATIONS: Wavelength:              980nm +/-3nm Power Output :            45mW at fiber coupler Mode:                        Multimode. Laser Diode Type:     SLI model SLI-CW-9MM-C1-980-0.3M-R Output Termination:  SMA fiber optic connector Operating Temp:       5 to 40 deg.C Diode Temp Reg:      +/- 0.2 deg.C Operation voltage:     +5VDC @ 500mA and                                   +12VDC @ 250mA, 1 Amp initial. See spec sheet. Input Connector:       16 pin dual in-line male .1" spacing. Not Included Dimensions:              170mm long x 38mm Diameter. (6.65" x 1.5") Mounting Threads:     #4 x 40 TPI X 4, 32mm (1.25") spacing Weight:                      255 Grams   Please See our other auctions for similar items.
