New Keyence Sr-751 Compact Barcode 2d Reader Kcc-rem-key-1169a Ethernet Sr751

US $340

Laredo, Texas, United States
Jun 9th

Open on mobile:
QR code

NEW KEYENCE SR-751 COMPACT BARCODE 2D READER KCC-REM-KEY-1169A ETHERNET SR751 See Pics Unit is new and sold as is. No cables. Product manual, details and specs can be viewed online. Reader will be properly packaged and promptly shipped via USPS. thanks for looking SR-650 - Ethernet-compatible Small 2D Code Reader, Short-distance Type Model SR-751*1 Languages Asynchronous Type Middle-range type Receiver Sensor CMOS Image Sensor Number of pixels 752 x 480 pixels Lighting Light source Red LED Laser pointer Visible semiconductor laser, Wavelength 660 nm Output 60 µW Pulse duration 200 µs Laser class Class 1 Laser Product (IEC60825-1, FDA (CDRH) Part 1040.10*2) I/O specifications Control input Number of inputs 2 Input type Bidirectional voltage input Maximum rating 26.4 VDC Minimum ON voltage 15 VDC Maximum OFF current 0.2 mA or less Control output Number of outputs 3 Output type Photo MOS relay output Maximum rating 30 VDC Maximum load current 1 output: 50 mA or less, Total of 3 outputs: 100 mA or less Leakage current when OFF 0.1 mA or less Residual voltage when ON 1 V or less Ethernet Communication standard 10BASE-T/100BASE-TX Supported protocol TCP/IP, FTP, SNTP, BOOTP, EtherNet/IP™, PROFINET, MC protocol, KV STUDIO Serial communication Communication standard RS-232C compliant Transmission speed 9600, 19200, 38400, 57600, 115200 bps Synchronization method Asynchronous Supported protocol Non-procedural, MC protocol, SYSWAY, KV STUDIO Reading specifications Minimum resolution 2D 0.19 mm 0.007" Barcode 0.127 mm 0.005" Supported symbol 2D QR, MicroQR, DataMatrix (ECC200), GS1 DataMatrix, PDF417, MicroPDF, Composite Code (CC-A, CC-B, CC-C) Barcode GS1DataBar,CODE39,ITF,NW-7 (Codabar),CODE128,GS1-128,JAN/EAN/UPC,CODE39 FullASCII, CODE93,2of5 (Industrial 2of5),COOP 2of5,Trioptic CODE39 Reading distance (typical examples) DataMatrix QR 45 to 165 mm 1.77" to 6.50" (Cell size = 0.5 mm 0.02") Barcode 45 to 195 mm 1.77" to 7.68" (Narrow bar width = 0.5 mm 0.02") Focal distance 100 mm 3.94" Field of view (at focal distance) 70.6 x 45.0 mm 2.78" x 1.77" Rating Power voltage Control port: 24 VDC±10% or Ethernet port: PoE TypeA/B 36 to 57 V (Cannot supply at the same time)*3 Current consumption Control port: 220 mA (When 24 VDC power supply is used) Ethernet port: PoE Power Class 2*4 Environmental resistance Enclosure rating IP65 Ambient temperature 0 to 45°C 32 to 113°F Ambient storage temperature -10 to +50°C 14 to 122 °F Operating ambient humidity 35 to 95% RH (No condensation) Storage ambient humidity Operating ambientluminance Sunlight: 10000 lux, Incandescent lamp: 6000 lux, Fluorescent lamp: 2000 lux Operating environment No dust or corrosive gas present Vibration 10 to 55 Hz Double amplitude 1.5 mm 0.06"/55 to 500 Hz: Acceleration 5G, 3 hours each in X, Y and Z directions Weight Approx 160 g *1 PROFINET is a trademark or registered trademark of PROFIBUS International. EtherNet/IP is a trademark or registered trademark of ODVA. *2 The laser classification for FDA (CDRH) is implemented based on IEC60825-1 in accordance with the requirements of Laser Notice No.50. *3 To comply with CSA No.61010-1/UL61010-1/IEC61010-1, use a power supply meeting the following criteria: - provides Class 2 output as defined in the CEC and NEC, or - evaluated as a Limited Power Source as defined in CAN/CSA-C22.2 No.60950-1/UL60950-1/IEC60950-1. *4 Peak operating current for PoE Power Class 2: 210 mA maximum.
