New Laserline Ldf 400-150 Fiber Coupled Diode Laser 150 W Cw 967 Nm Laser Line

US $12,499.99

Phoenix, Arizona, United States
Jan 30th

Open on mobile:
QR code

NEW Laserline LDF 400-150 Fiber Coupled Diode Laser Comes with a manual and what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from Laserline and may vary slightly due to upgrades, options, or revisions this unit may or may not have. 2 units available, only 1 sold in the auction. These units came out of a defense contractor and look to have very little use. The laser red cover was removed and the hour meter showed 0 use which is why they are advertised as NEW. There was anti-freeze/water in the cooling line to the factory from the manufacturer I believe. They are sold as-is. The Main Unit's Serial Number Tag Reads: Model Number: LDF 400-150 Serial Number: 211861-1 Power Requirements: 480 VAC, 60 Hz, 1.8 kW Year of Manufacture: 2002 CE Marked: Yes The Laser Head's Serial Number Tag Reads: Model Number: LDF 400-150 Serial Number: 211861-1 Power: P = 150 W cw Wavelength: λ = 967 ±3 nm The Transformer's Serial Number Tag Reads: Type: TDSG 3 3.5 kVA Primary Voltage: 3 Phase, 480 V ±5%, 50/60 Hz, 2.44 A Secondary Voltage: 3 Phase, 400 V, 5 A Class: IP 54 CE Marked: Yes Advantages: At higher laser powers in smaller fibers the new generation of fiber-coupled diode lasers offers the known advantages: High efficiency (> 30%) Long lifetime Low maintenance costs Use in rough environment possible New Features: All-in-one unit Increased optical output power Improved beam quality and therefore working distance and smaller focal spot Tele diagnostics/tele service integrated Redundant diode laser stacks increase system availability Supply system and laser in one mobile unit Modular working optics provides high flexibility Temperature and rupture monitoring of fiber Applications: The new fiber-coupled diode lasers allow further industrial applications: Deeper welding seams in metals Higher welding speed Micro welding Cutting of metals and plastic materials Brazing with high laser power Reduced heat affected zone Auxiliary Components: Modular optics for cutting, welding, soldering and surface treatment Inside working optics and other custom optics Additional modules can be integrated (welding sensors, CCD camera, pyrometer, protection glass monitoring, crossjet) Shutter Specifications: Beam Source: LDF 400 Laser Power: 100-200 W, 100-300 W (This laser is marked 150 W) Beam Quality: 26 mm-mrad, 40 mm-mrad (I didn't really see an indication anywhere but the lens with it says f=80 mm) Diameter of Fiber: 400 µm Numerical Aperture: 0.13, 0.2 For More Pictures Please Click the Following: Picture 2 - Front View, Panel Open Picture 3 - Back View Picture 4 - Back View, Panel Open Picture 5 - Right Side View Picture 6 - Right Side View, Panel Open Picture 7 - Left Side View Picture 8 - Left Side View, Panel Open Picture 9 - Front Panel Controls Picture 10 - Laser, Right Side Picture 11 - Laser, Left Side Picture 12 - Transformer, Panel Open Picture 13 - Transformer's Serial Number Tag Picture 14 - Laser's Serial Number Tag Picture 15 - Main Unit Serial Number Tag $100.00 minimum for packaging, handling, and order processing. Shipping to be determined by destination. Prior to shipment I need to know the following information: (1) Are you the end-user of this item? (2) If you are not the ultimate end-user of the item, please state the ultimate end user's name. (3) What is the ultimate country destination? If you have any questions please call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 09/25/10 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.

Condition	New other (see details) : A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“2 units available, only 1 sold in the auction. These units came out of a defense contractor and look to have very little use. The laser red cover was removed and the hour meter showed 0 use which is why they are advertised as NEW. There was anti-freeze/water in the cooling line to the factory from the manufacturer I believe. They are sold as-is.”
