New Made To Order 3 Liter Cmx/axomatic Minimix Homogenizer Mixer - 316l S/s

US $45,500.00

Bohemia, New York, United States
Jan 30th

Open on mobile:
QR code

ARNOLD EQUIPMENT COMPANY INVENTORY #7981 - 1 - NEW 3 liter working (4 liter total/1 liter minimum working) capacity laboratory Mixer Homogenizer Turbo Emulsifier manufactured by CMX Process Technologies/Axomatic. All product contact parts to be type 316L stainless steel, mirror polished. All elastomers (including mechanical seal "O" rings) to be FDA approved Viton. Exterior of vessel and cover to be polished to a fine satin surface finish. Monoblock lift housing and drive supporting structure to be fabricated of and/or sheathed with type 304 stainless steel polished to a fine satin surface finish. Unit designed for full vacuum operation (-1 BarG). Agitation system for mixing and homogenizing medium to high viscosity formulations consists of two top entering coaxial agitators and one top entering homogenizing turbine, including: Outer anchor agitator with self-adjusting teflon scrapers (10-75 rpm) and internal counter-rotating blades (20-150 rpm) driven by a 0.37 kw, 230 or 460 volt, 60 hz TEFC motor. Top entering rotor/stator type homogenizer (355-3550 rpm) driven by 0.56 kw, 230 or 460 volt, 60 hz, TEFC motor. AC variable frequency inverter drives located in the monoblock enclosure. All motors, instruments and sensors on the unit to be wired to the control panel mounted inside of the monoblock enclosure. Coaxial and homogenizing turbine shaft sealing arrangements utilize mechanical seals with viton o-rings. Vacuum cover with (1) 2.5 in. pyrex sight glass with teflon wiper blade, (1) 1.5 in. tri-clamp connection with sight glass and light source, (1) 3/4 in. tri-clamp connection for vacuum line, (2) 3/4 in. tri-clamp connections ingredient addition and vacuum/pressure transmitter. Offered with either a tilting or removable vessel with type 304 stainless steel jacket with self contained electrical heating system mounted in the monoblock enclosure. Heating/cooling system includes reservoir, centrifugal water circulation pump (30 L/min, 0.25 kw) and electrical heating element (2 kw). Safety thermostat. Vessel and product cooling obtained through city water circulation through vessel jacket. Temperature control is programmed through the PLC and touch-screen graphical user interface. Pt-100 ohm RTD probe located in heating/cooling loop for jacket temperature measurement. Removable vessel type with monoblock configuration and electromechanical lifting arrangement to raise the vacuum cover and agitators from the vessel. Safety limit switches and interlocks to prevent operation of drives when vacuum cover is in lifted position or when vessel is removed from mixer. Safety limit switch and interlocks to prevent lifting of vacuum cover if the vessel is under vacuum or pressure. All utility and process connections are manifolded inside of the monoblock structure for connection on the rear of the unit. Air ejector type venture vacuum pump installed in the monoblock enclosure. Controls and instrumentation located integrally in mono-block cabinet to include: Safety interlock logic, AC variable frequency inverter drives for independent variable speed control of the agitators. The following controls mounted on the front of the cabinet: main power disconnect, control ppower light, emergency stop button. Touch screen operator interface and PLC for control of all functions of the system including: cover lifting operation, agitator operation, heating/cooling control, vacuum/pressure control. Input voltage: 230 or 460 volts, 3 phase, 60 hz. Tilting vessel configuration: Driven through a manually actuated gear reducer and a hand wheel. Vessel can tilts to approx. 95 deg. position. Heating/cooling connections enter the jacket through special rotary pressure joints. Safety limit switches and interlocks to prevent operation of drives when mixing vessel is tilted. Please note, vessel is NOT removable with the tilting configuration. The following options are available for an additional cost: Vessel insulation: Vessel jacket is insulated with non-chloride insulating material and fully enclosed with type 304 stainless steel sheathing welded to vessel: Price adder: $850.00. Internal pressure: Unit designed for full vacuum operation (-1 BarG) and internal pressure to 7.3 psig (0.5 BarG): Price adder: $3,400.00. Unit designed for full vacuum operation (-1 BarG) and internal pressure to 14.5 psig (1 BarG): Price adder: $7,100.00. Shipment: 2-3 months (Depending on features) after receipt of order and 50% down payment. Terms: 50% with order, balance upon completion of construction, prior to shipment. F.O.B. - BOHEMIA, NY

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	CMX Process Technologies (Axomatic)
Model	MiniMix 3L
