New! Marathon G047, .33hp, 1725rpm, 56 Fr., 230/460, Odp, 3ph, 56t17d2095, G047a

US $4800

Griffith, Indiana, United States
Jun 13th

Open on mobile:
QR code

NEW!! Marathon electric motor, 1/3hp, .33 hp, 1725 rpm, 56 frame, 230/460 volts, 3 phase, 60 hz, ODP, catalog #G047, G047, foot mount, 1740rpm, 1750rpm, 1800rpm, 56, Foot mounting, .33hp, 1725rpm, 56 frame, Marathon, .33hp, 1/3 hp, 3 ph, 1725rpm, 056T17D2095, 56T17D2095, G047A, 056T17D11049, 56T17D11049, 1425 rpm, 50/60hz, 50/60, Marathon motor, For more information call Mike Burvan @ 219-922-2668, burv@jorsm.com or visit www.midwestpowerproducts.com Description 230/460 Volt 56 Frame Shaft Diameter - 5/8" 1725 RPM ODP Our stock #648 HP: 1/3, .33 RPM: 1725, 1730, 1735, 1740, 1745, 1750, 1755, 1760, 1765, 1770, 1775, 1800, 1425, 1500 Voltage: 230/460, 190/380 vac Phase: 3 Hertz: 60, 50 Frame: 56 Mounting: Foot mount Enclosure: ODP Manufacturer: Marathon Electric Model #: G047, 56T17D2095, 056T17D2095, G047A, 056T17D11049 Notes: New in box!! CERTIFICATION DATA SHEET MODEL#:56T17D2095K WINDING#:TE48414NONE3 CONN. DIAGRAM:A-EE7308 ASSEMBLY:F1 ONLY OUTLINE:A-SS75081-600 TYPICAL MOTOR PERFORMANCE DATA HP kW SYNC. RPM F.L. RPM FRAME ENCLOSURE KVA CODE DESIGN 1/3&1/4 0.25&0.19 1800 1725&1425 56 DP N B PH Hz VOLTS FL AMPS START TYPE DUTY INSL S.F. AMB ELEVATION 3 60/50 208-230/460&190/380 1.5-1.6/.8&1.6/.8 ACROSS THE LINE CONTINUOUS B3 1.35/1.35 40 3300 FULL LOAD EFF:66&64 3/4 LOAD EFF:60 1/2 LOAD EFF:51 GTD. EFF ELEC. TYPE NO LOAD AMPS FULL LOAD PF:56&57.5 3/4 LOAD PF:50 1/2 LOAD PF:40.5 64 SQ CAGE IND RUN 1.5 / .7 F.L. TORQUE LOCKED ROTOR AMPS L.R. TORQUE B.D. TORQUE F.L. RISE 1 LB-FT 9.4 / 4.7 4.3 LB-FT430% 4.7 LB-FT470% 30 SOUND PRESSURE @ 3 FT. SOUND POWER ROTOR WK^2 MAX. WK^2 SAFE STALL TIME STARTS / HOUR APPROX. MOTOR WGT 56 dBA 66 dBA 0.035 LB-FT^2 - LB-FT^2 10 SEC. - 17 LBS. *** SUPPLEMENTAL INFORMATION *** DE BRACKET TYPE ODE BRACKET TYPE MOUNT TYPE ORIENTATION SEVERE DUTY HAZARDOUS LOCATION DRIP COVER SCREENS PAINT STANDARD STANDARD RIGID HORIZONTAL FALSE NONE FALSE NONE STANDARD BEARINGS GREASE SHAFT TYPE SPECIAL DE SPECIAL ODE SHAFT MATERIAL FRAME MATERIAL DE ODE BALL BALL STANDARD T NONE NONE STANDARD ROLLED STEEL 6203 6203 THERMO-PROTECTORS THERMISTORS CONTROL SPACE HEATERS THERMOSTATS PROTECTORS WDG RTDs BRG RTDs NONE NONE NONE NONE FALSE NONE VOLTS * N O T E S * DATE: 08/26/2012 03:55:45 PM FORM 3531 REV.3 02/07/99 ** Subject to change without notice. INVERTER TORQUE:NONE INV. HP SPEED RANGE:NONE ENCODER:NONE NONE NONE NONE NONEPPR BRAKE: NONE NONE NONE P/NNONE NONE NONE - FT-LB NONE V NONE Hz Catalog Number: G047 Dim Drawing: A-SS75081-600 Model Number: 056T17D2095 Conn Diagram: A-EE7308 List Price: Price Unavailable Certification Data Sheet Certification Data Sheet in PDF Multiplier Symbol: F1 Installation, Maintenance, Operation Manual Normally Stocked: Y ****Motor Nameplate Shows 60 and 50 Hertz Information**** 60 Hertz HP 1/3 Voltage 208-230/460 kW 0.25 FL Amps 1.5-1.6/.8 RPM 1800 FL Eff 66 % SF 1.35 50 Hertz HP 1/4 Voltage 190/380 kW 0.19 FL Amps 1.6/.8 RPM 1500 FL Eff 64 % SF 1.35 Phase 3 Insulation Class B Frame 56 Duty CONTINUOUS Enclosure DP Ambient 40 Mounting Rigid NEMA Design B Orientation HORIZONTAL Starting Type ACROSS THE LINE Assembly F1 ONLY KVA Code N Drive End Bearing BALL IP Code 22 Opposite End Bearing BALL Drive End Bearing Size 6203 Opposite End Bearing Size 6203 Weight 15 LB lbs CE N CSA Y UL Recognized Construction Thermal Protection General purpose with continuous duty rating. Standard operating characteristics and mechanical construction for use under usual service conditions without restriction to a particular application or type. Not for outdoor use. FEATURES: Rigid base Dripproof 1.35 Service factor Ball bearings 5/8" shaft diameter UL Recognized and CSA Certified Motor will NOT accept C-Face kits Rated 60/50 hertz, 190/380 or 380 volt at next lower horsepower Phase 3 Insulation Class B Frame 56 Duty CONTINUOUS Enclosure DP Ambient 40 Mounting Rigid NEMA Design B Orientation HORIZONTAL Starting Type ACROSS THE LINE Assembly F1 ONLY KVA Code N Drive End Bearing BALL IP Code 22 Opposite End Bearing BALL Drive End Bearing Size 6203 Opposite End Bearing Size 6203 Weight 15 LB lbs CE N CSA Y UL Recognized Construction Thermal Protection Catalog Number: G047A Model Number: 056T17D11049 Description: 1/3HP,1800RPM,56,208-230/460V,DP,3PH,60/50HZ
