New Moxa Mb3170 1-port Advanced Serial-to-ethernet Modbus Gateway Nib!!

US $250.00

Vega Baja, Puerto Rico, United States
Jan 29th

Open on mobile:
QR code

Features and Benefits Configuration is exceptionally easy Slave mode supports 16 TCP masters and up to 31 or 62 serial slaves at the same time Master mode supports 32 TCP slaves at the same time Emergency request tunnels ensure QoS control Serial redirector function provided Embedded Modbus protocol analyzer Redundant dual DC power inputs Built-in Ethernet cascading for easy wiring * MGate MB3170/3270 Modbus gateway has received Taiwan Excellence and Good Design awards. Overview The MB3170 and MB3270 are advanced Modbus gateways that provide maximum flexibility for integrating industrial Modbus networks of all types and sizes. They are designed to integrate Modbus TCP, ASCII, and RTU devices in almost any master and slave combination, including serial master to serial slave, or simultaneous serial and Ethernet masters. A special priority control feature allows urgent commands to obtain an immediate response. All models are ruggedly constructed, are DIN-rail mountable, and offer built-in optical isolation for serial signals as an option. Integration of TCP masters without alteration to Modbus RTU/ASCII network or software The MB3270 can integrate Modbus TCP with Modbus RTU/ASCII, without modifying the existing Modbus RTU/ASCII architecture or software. With the serial redirector function, a serial master can maintain direct access to serial slave devices through a specially mapped serial port. This allows the serial and TCP masters to access serial slaves simultaneously. Cascading Ethernet ports for easy wiring Advanced models of the MGate™ MB3000 series have two Ethernet ports to make network wiring easier. Dual Ethernet ports allow users to string multiple Modbus gateways together using standard RJ45 Ethernet cables, eliminating the need for a separate Ethernet switch. Redundant power inputs Advanced models of the MB3000 series have dual power inputs for greater reliability. The power inputs allow simultaneous connections to two live DC power sources, so that continuous operation is provided even if one power source fails. The higher level of reliability makes these advanced Modbus gateways ideal for demanding industrial applications. Warning by relay output A relay output is provided for the Ethernet link and power input status. The relay output gives maintenance engineers an additional tool for troubleshooting and maintenance. Ethernet Interface Protocol Modbus TCP Number of Ports 2 (1 IP, Ethernet cascade) Speed 10/100 Mbps, Auto MDI/MDIX Connector 8-pin RJ45 Magnetic Isolation Protection 1.5 kV (built-in) • Serial Interface Protocol Modbus RTU/ASCII Slave/Master Number of Ports MB3170/3170I: 1 MB3270/3270I: 2 Serial Standards RS-232/422/485, software selectable Connectors MB3170/3170I: DB9 male for RS-232, terminal block for RS-422/485 MB3270/3270I: DB9 male x 2 Magnetic Isolation Protection 2 kV (for “I” models) ESD Protection 15 kV for all signals RS-485 Data Direction Control ADDC® (automatic data direction control) Pull High/Low Resistor for RS-485 1 k?, 150 k? Terminator for RS-485 120 ? • Serial Communication Parameters Data Bits 7, 8 Stop Bits 1, 2 Parity None, Even, Odd, Space, Mark Flow Control RTS/CTS, DTR/DSR (RS-232 only) Baudrate 50 bps to 921.6 kbps • Serial Signals RS-232 TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND RS-422 Tx+, Tx-, Rx+, Rx-, GND RS-485-4w Tx+, Tx-, Rx+, Rx-, GND RS-485-2w Data+, Data-, GND • Software Configuration Options Web Console, Serial Console, Telnet Console, Windows Utility Utility MGate Manager for Windows 2000/XP/2003/Vista/Server 2008/7/8 (x86/x64), Windows Server 2008 R2/2012 (x64) Multi-master and Multi-drop Master mode: 32 TCP slaves Slave mode: 16 TCP masters (request queue 32-deep for each master) Support Smart Routing, Serial Redirection, ProCOM, Priority Control, MXview, SNMP v1 (read only) • Physical Characteristics Housing Plastic Weight MGate MB3170: 360 g MGate MB3270: 380 g Dimensions Without ears: 29 x 89.2 x 118.5 mm (1.14 x 3.51 x 4.67 in) With ears extended: 29 x 89.2 x 124.5 mm (1.14 x 3.51 x 4.90 in) • Environmental Limits Operating Temperature Standard Models: 0 to 60°C (32 to 140°F) Wide Temp. Models: -40 to 75°C (-40 to 167°F) Storage Temperature -40 to 85°C (-40 to 185°F) Ambient Relative Humidity 5 to 95% (non-condensing) Altitude Up to 2000 m (795 hPa), higher altitudes on demand Note Please contact Moxa if you require products guaranteed to function properly at higher altitudes. • Power Requirements Input Voltage 12 to 48 VDC Power Connector Terminal block Power Consumption MGate MB3170: 435 mA (max.) MGate MB3170I: 555 mA (max.) MGate MB3270: 435 mA (max.) MGate MB3270I: 510 mA (max.) Relay Output 1 digital relay output to alarm (normal close): Current carrying capacity 1 A @ 30 VDC • Standards and Certifications Safety UL 508, EN 60950-1 Hazardous Location UL/cUL Class 1 Division 2 Groups A/B/C/D, ATEX Zone 2 Ex nA IIC T3 Gc, IECEx (-IEX model only) EMC CE, FCC EMI EN 55022 Class A, FCC Part 15 Subpart B Class A EMS EN 55024, EN 61000-4-2 (ESD) Level 3, EN 61000-4-3 (RS) Level 3, EN 61000-4-4 (EFT) Level 4, EN 61000-4-5 (Surge) Level 3, EN 61000-4-6 (CS) Level 3, EN 61000-4-8 (PFMF) Level 1, EN 61000-4-11 Marine DNV Shock IEC 60068-2-27 Freefall IEC 60068-2-32 Vibration IEC 60068-2-6 • Reliability MTBF (mean time between failures) MGate MB3170: 210,794 hrs MGate MB3270: 125,234 hrs • Warranty Warranty Period 5 years Details See www.moxa.com/warranty

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Moxa
Model	MB3170
