New Murrelektronik 7000-14541-7961000 M12 Male D-coded Ethernet 4-wire 10m

US $40.00

Atlanta, Georgia, United States
Aug 9th

Open on mobile:
QR code

This is NEW, unused surplus inventory, and has never been used Ethernet CAT5 Male straight M12, 4-pole D-coded shielded Plastic housings with good resistance against chemicals and oils. The resistance to aggressive media should be individually tested for your application. Cable number 796 No./diameter of wires 2 2 0.34 mm Wire isolation PO (wh, ye, bl, or) C-track properties 3 Mio. Jacket Color green Material (jacket) PUR (UL/CSA) Outer 6.7 mm ±5% Bend radius (moving) 12 outer Temperature range (fixed) -40...+80 °C Temperature range (mobile) -30...+70 °C Cable identification 796 Approval (cable) UL (AWM-Style 20233/11602), CSA; CE Cable weight [g/m] 69,30 Material (wire) Cu wire, bare Resistor (core) max. 55 Ohm/km (20 °C) Diameter (core) 2(2AWG22) Material (wire isolation) PO Wire- incl. isolation 1.4 mm ±5% Color/numbering of wires wh, ye, bl, or Shield yes min. 85% Material (jacket) PUR Outer- (jacket) 6.7 mm ±5% Color (jacket) green thermal resistance flame retardant Nominal voltage 300 V Temperature range (fixed) -40...+80 °C Temperature range (mobile) -30...+70 °C Bend radius (fixed) 5 outer Bend radius (moving) 12 outer Number of bending cycles (C-track) max. 3 Mio. (25 °C) Traversing distance (C-track) max. 5 m (horizontal) Travel speed (C-track) max. 3.3 m/s Acceleration (C-track) max. 2 m/s TECHNICAL DATA Operating voltage max. 60 V DC Operating voltage (only UL listed) max. 30 V DC Rated surge voltage 1.5 kV Operating current per contact max. 4 A Material group IEC 60664-1, category I Transfer parameters CAT5, Class D (ISO/IEC 11801:2002), (EN 50173-1) Transfer rate to 100 Mbit/s Full Duplex Coding D-coded Locking of ports Screw thread M12 1 mm (recommended torque 0.6 Nm) self-securing Compression gland M12 (SW13) Protection IP65, IP66K, IP67 inserted and tightened (EN 60529) Locking material Zinc die casting, matte nickel plated Material PUR suitable for corrugated tube (internal ) without GENERAL DATA Standards DIN EN 61076-2-101 (M12) Pollution Degree 3 Temperature range -25...+85 °C, depending on cable quality COMMERCIAL DATA country of origin DE customs tariff number 85444290 EAN 4048879197434 eClass 27061801 Packaging unit 1

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	7000-14541-7961000
Brand	Murrelektronik
Number of Cores	4
Wire Gauge	2x 2x22AWG
MPN	7000-14541-7961000
IP Rating	IP67
UPC	Does not apply
