New National Instruments Ni Pxi-4461, 24-bit, 204.8 Ks/s, 2 Inputs/2 Outputs Dsa

US $1,150.00

Kossice, Slovakia
Jan 29th

Open on mobile:
QR code

NI PXI-446124-Bit, 204.8 kS/s, 2 Inputs/2 Outputs New, unused item, only PXI card in original pack Two simultaneously updated analog outputs at up to 204.8 kS/s Software-configurable AC/DC coupling and IEPE conditioning 24-bit resolution ADCs and DACs with 118 dB dynamic range Variable antialiasing and anti-imaging filters Six gain settings for input ranges from ±316 mV to ±42.4 V Two simultaneously sampled analog inputs at up to 204.8 kS/s Manufacturing price: $4000 More information The National Instruments PXI-4461 is a high-accuracy data acquisition module specifically designed for sound and vibration applications. This module includes the hardware and software needed to make precision measurements with microphones, accelerometers, and other transducers that have very large dynamic ranges. Common applications include audio test, automotive NVH, and machine condition monitoring. Best Value: Buy both and save. The NI PXI-4461 is also available as a bundle with the NI Sound and Vibration Measurement Suite, which includes NI Sound and Vibration Assistant, at a discount from the list price. See theResources tab for more information on the list of analysis capabilities of the Sound and Vibration Measurement Suite. Multidevice Synchronization For applications requiring up to thousands of channels, you can synchronize the operation of two or more NI 446x devices with less than 0.1 deg of phase mismatch between channels. Hybrid Slot-Compatible PXI Modules The NI PXI-4461 is available in both PXI and PXI Express hybrid slot-compatible form factors. You can use the hybrid slot-compatible PXI-446x modules in PXI slots, CompactPCI slots, and hybrid slots, found in new PXI Express chassis. General Product Name PXI-4461 Product Family Dynamic Signal Analyzers Form Factor PXI Platform PXI Bus Type PXI Hybrid Compatible Part Number 778442-01 Operating System/Target Real-Time , Linux , Windows LabVIEW RT Support Yes Power Requirement for +3.3V Rail 0.99 A Power Requirement for +5V Rail 1.4 A Power Requirement for +12V Rail 170 mA Power Requirement for -12V Rail 110 mA Slot Two Module No Module Width 1 MXI Compatible Yes Measurement Type Accelerometer , Voltage RoHS Compliant Yes Signal Conditioning Current excitation , Anti-aliasing filter Analog Input Channels 2 , 0 Single-Ended Channels 0 Differential Channels 2 Resolution 24 bits Sample Rate 204.8 kS/s Max Voltage 42.4 V Maximum Voltage Range -42.4 V - 42.4 V Maximum Voltage Range Sensitivity 5.05 µV Minimum Voltage Range -316 mV - 316 mV Minimum Voltage Range Sensitivity 37.7 nV Number of Ranges 6 Simultaneous Sampling Yes On-Board Memory 2047 samples Dynamic Range 118 dB Excitation Current 10 mA Analog Output Channels 2 Resolution 24 bits Max Voltage 10 V Maximum Voltage Range -10 V - 10 V Maximum Voltage Range Sensitivity 1.19 µV Minimum Voltage Range -100 mV - 100 mV Minimum Voltage Range Sensitivity 11.9 nV Update Rate 204.8 kS/s Current Drive Single 16.67 mA Digital I/O Bidirectional Channels 0 Input-Only Channels 0 Output-Only Channels 0 Counter/Timers Counters 0 Physical Specifications Length 16 cm Width 10 cm I/O Connector SMB female , BNC connectors Timing/Triggering/Synchronization Triggering Digital , Analog Synchronization Bus (RTSI) Yes

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	National Instruments
Country of Manufacture	Hungary
Model	NI PXI-4461
